Push-in seals

M

Type Nominalsizes Colour Packqty Weightkg/100 Ord. no. PE
øD1øD2 Ø 20Ø 25 Ø 32 10010050 0.150 0.180 0.700 2012375 2012383 2012391 L Suitable for: EDVS 20: Damp-proof junction boxesVBX 25 Msee page 15B 25 Msee page 19B 40 Msee page 20B 60 Msee page 20EDVS 25: Damp-proof junction boxesVBX 60 Msee page 16B 100 Msee page 21EDVS 32: Damp-proof junction boxesB 160 Msee page 21B 250 Msee page 22
Type For cableØ mmD1mmD2mmEDVS 20EDVS 25EDVS 321-17.51-211-25.524.829.536.320.325.332.3 LmmAmm12.814.517.83.44.34.4 EDVS ...: Can be cut back to suit the relevant cable diameter PE Polyethylene, light grey (RAL 7035)Flame-retardant to VDE 0471/DIN IEC 695 Part 2-1Test temperature 750 ° C

Connecting plugs

Type Nominalsizes Colour Packqty Weightkg/100 Ord. no. PE M 32 20 1.000 2011263 Suitable for: VB 32 M: For direct connection of damp-proof junction boxes B 160 M andB 250 M Damp-proof junction boxesB 160 Msee page 21B 250 Msee page 22 PE Polyethylene, light grey (RAL 7035)

Entry plugs

ø D
t L ø d
Type Nominalsizes Colour Packqty Weightkg/100 Ord. no. PE 1001005025 0.1000.1100.3000.400 20121542012162 20121702012189
Type NominalsizeDmmdmmVS 13VS 16VS 21VS 29Pg 13.5Pg 16 Pg 21Pg 2925.627.3 334421.122.829.138.1 Lmmtmm9912152.62.6 4.35.3 Suitable for: VS 13: Damp-proof junction boxesVBX 25see page 15 VS 21: Damp-proof junction boxesVBX 60see page 16 VS ...: To blank off holes not required in junction boxes series B 25-250 andVBX 25, VBX 60 PE Polyethylene, light grey (RAL 7035) Please always state the ordering number when ordering.

27
