Bifurcated cable glands
28
halogen-free
chlorine fluorine bromine
Type
Nominal sizes
Colour
Pack qty
Weight kg/100
Ord. no. UF
113/13.5 113/16
Pg 13.5
Pg 16
1. grey 1. grey
5 5
4.672 4.356
202413 6 202416 0
54.5
With 2 half-glands Pg 13.5
113/...: Protection IP 54,
with removable lid of polystyrene, and 2 connecting thread gaskets of polyethylene
113/13.5: With connecting thread Pg 13.5, 2 half-glands Pg 13.5 for cable 0 6.5-10.5 mm
113/16: With connecting thread Pg 16,
2 half-glands Pg 13.5 for cable 0 6.5-10.5 mm
UF Duroplast/aminoplast 131.5 (UF), light grey (RAL 7035), difficult to ignite
28
halogen-free
chlorine fluorine bromine
Type
Nominal sizes
Colour
Pack
qty
Weight
kg/100
Ord. no. UF
113/M20
M20X1.5
I. grey
5
4.672
2024 06 3
54.5
With 2 half-glands Pg 13.5
113/M Protection IP 54, with removable lid of polystyrene, and 2 connecting thread gaskets of polyethylene
113/M 20: With connecting thread M20 x 1.5, 2 half-glands Pg 13.5 for cable 0 6.5-10.5 mm
UF Duroplast/aminoplast 131.5 (UF), light grey (RAL 7035), difficult to ignite
Push-in seals
A
Type
Nominal
Colour
Pack
Weight
Ord. no.
sizes
qty
kg/100
PE
ED 13
Pg 13.5
1. grey
100
0.150
2012 70 7
ED 16
Pg16
1. grey
100
0.180
2012 72 3
ED 21
Pg21
1. grey
50
0.700
2012 73 1
ED 29
Pg29
1. grey
25
1.100
2012 86 3
ED29/K
Pg29
1. grey
25
1.100
2012 89 8
û
Type
For cable
D1
D2
L
A
d1
d2
d3
d4
0 mm
mm
mm
mm
mm
mm
mm
mm
mm
ED 13
8-15.5
26.5
22.7
20.5
2.8-3.4
7
10.5
-
-
ED 16
8-19.5
25.7
22.8
28
2.6-3.2
8
15
-
-
ED 21
8-23.5
33
29
26
3.9-4.4
7
10.5
14.5
18.5
ED 29
13-29
44
38.1
45
5.1-5.9
11.5
22
-
-
ED 29/K
3-29
44
38.1
45
5.1-5.9
2.5
22
-
-
Suitable for:
ED 13: Damp-proof junction boxes VBX 25 see page 15
ED 21: Damp-proof junction boxes VBX 60 see page 16
CM
o o
CM CM
o
CM
>¡
m
C5
co m >
ED Can be cut back to suit the relevant cable diameter PE Polyethylene, light grey (RAL 7035)
26
Please always state the ordering number when ordering.
