M
58 58
71 32 halogen-free chlorinefluorinebromine 64 144 Type Colour Cartonqty Packqty Weightkg/100 Ord. no. UF 178 (fixing holes) 1212 1
1 96.700
65.500 2002507
2002523 196 B 12 M ...: Protection IP 54, rated voltage 660 V,nominal cross-section 16 mm
2 2 fixing holes for screws up to 6 mm diameter on the outside of the box4 lid screws, 10 breakout entries with thread M25 x 1.5Clear internal dimensions: 126 x 178 x 57 B 12/16 M: With five-pole terminal strip KL 160 of melamine,with clamp terminals for max. three 16 mm
2 conductors per terminal B 12 M empty: Without terminal strip UF Duroplast/aminoplast 131.5 (UF), light grey (RAL 7035),difficult to ignite
Cable connection sleeves
ø28 64 117/2.5 VDE 117/... VDE: Protection IP 54, rated voltage 660 V
Type Colour Packqty Weightkg/100 Ord. no. 117/2.5 VDE: Nominal cross-section 2.5 mm
2 ,with five pole terminal insert 2.5 mm PS
2 and cable entries with strain reliefPg 16 for cable Ø 9-14 mm117/6 VDE 105 5.31014.600 2022028
2022060
ø33.5 82 117/6 VDE: Nominal cross-section 6 mm
2 ,with five-pole terminal insert 6 mm
2 and cable entries with strain relief Pg 21for cable Ø 12-18 mmIn accordance with VDE, cable connection sleeves are only intended forfixed installations. PS Polystyrene Please always state the ordering number when ordering.
25
