M
42
halogen-free 51 chlorinefluorinebromine 25.7 Type Colour Cartonqty Packqty Weightkg/100 Ord. no. UF 8080 5
5 22.480
17.360 2002140
2002167
(fixing holes)78.2 91 Accessories available: Terminal blocks700/4 BMsee page 30700/6 Msee page 31 B 10 M ...: Protection IP 54, rated voltage 660 V,nominal cross-section 2.5 and 4 mm
2 In combination with
terminal block 700/6 M, the box has a nominal cross-section of 4 mm
2 .2 fixing holes for screws up to 5 mm diameter on the outside of the box
4 lid screws, 7 breakout entries with M20 x 1.5 thread, primarily for cableglands with short connecting threadClear internal dimensions: 80 x 80 x 39 B 10/4 M VDE: With five-pole terminal block 700/4 BM of melamine for max.four 2.5 mm
2 conductors per terminal UF Duroplast/aminoplast 131.5 (UF), light grey (RAL 7035),difficult to ignite 40.25 40.25
M
57 25 halogen-free chlorinefluorinebromine Type Colour Cartonqty Packqty Weightkg/100 Ord. no. UF
111 52.5 2424 1
1 39.700
32.200 2002329
2002345 125 (fixing holes) 136 Accessories available: Terminal stripsKL 100see page 30 B 11 M: Protection IP 54, rated voltage 660 V,nominal cross-section 10 mm
2 2 fixing holes for screws up to 6 mm diameter on the outside of the box4 lid screws, 10 breakout entries with M20 x 1.5 thread, primarily for cableglands with short connecting threadClear internal dimensions: 125 x 100 x 44 B 11 M/L: With five-pole terminal strip KL 100,with clamp terminals for max. three 10 mm
2 conductors per terminal B 11 M empty: Without terminal strip UF Duroplast/aminoplast 131.5 (UF), light grey (RAL 7035),difficult to ignite
24
Please always state the ordering number when ordering.
