Floor care types and the selection of the installation units
Correct selection of the installation units
0B0 underfloor systems contain various installation units, intended to
etc.). A key criterion for the selection o( the correct installation units is the type of industrial floor covering. A distinction is made between care types, as the installation device - for example, the construction of the industrial seal against moisture ingress - must be matched to the planned cleaning method. The grading into the care categories is regulated in the standard DIN VDE 0634 Part 1.
Dry care
The criterion for "dry care" is primar­ily met by textile tloor coverings, which are ("dry") cleaned regularly by vacuuming up the dirt. Here, the standard talks of "water-free or low-water cleaning methods" and also defines that, should cleaning solu­tions be used, there should be so little used that no "pool formation or water penetration of the floor cover­ing" is possible.
Damp care
The preconditions for the use of the "damp care" method are fulfilled by smooth floor coverings, such as linoleum, PVC, sealed wooden floors, polished stone floors, etc. The build­ing cleaning profession defines this type of care as "dust-binding wiping using moistened or prepared clean­ing textiles" - you can find an exact description of the care methods in the building cleaning handbook,
22 UFS
