Modul 45 surge protection


Surge protection device type 3 (class D) to VDE 0675 part 6-11 (DIN EN 61643-11)	Type	Colour	Pack, pc	Weight kg/% pc	Art. No.	Price €/pc	Discount group
With optical function indication.	ÜSS 45-O	pure white	1	2.411	6117 47 3		L
	ÜSS 45-O	aluminium painted	1	2.411	6117 47 5
With acoustic function indication.	ÜSS 45-A	pure white	1	2.579	6117 46 5		L
	ÜSS 45-A	aluminium painted	1	2.579	6117 46 7

For stationary installation in Rapid 45 ducts, skirting ducts and underfloor systems.

• Version -O with optical function indication.

• Version -A with acoustic function indication (signal tone can be shut down}.

• Quick and easy installation

• Installation width only 22.5 mm.

Application: The installation of the surge protection device, which is performed by the electrical installer, secures individual sockets, but can also be used for protecting socket combinations.

Modul 45 installation devices

Changeover switch


Type	Colour	Pack, pc	Weight kg/% pc	Art. No.	Price €/pc	Discount group
WS / 45	pure white	10	2.600	6117 554		L
WS / 45	aluminium painted	10	2.600	6117 55 6

Changeoverswitch Modul 45.


Type	Colour	Pack, pc	Weight kg/% pc	Art. No.	Price €/pc	Discount group
TA / 45	pure white	10	2.300	6117 56 2		L
TA / 45	aluminium painted	10	2.300	6117 564

Switch

Modul 45 switch.


Type	Colour	Pack, pc	Weight kg/% pc	Art. No.	Price €/pc	Discount group
JS / 45	pure white	10	3.700	6117 57 0		L
JS / 45	aluminium painted	10	3.700	6117 57 2

Venetian blind switch

Venetian blind switch Modul45.


Type	Colour	Pack, pc	Weight kg/% pc	Art. No.	Price €/pc	Discount group
JT / 45	pure white	10	3.700	6117 57 7
JT / 45	aluminium painted	10	3.700	6117 57 9

Blind switch

Modul 45 blind switch


Type	Colour	Pack, pc	Weight kg/% pc	Art. No.	Price €/pc	Discount group
ANT / 45	pure white	10	6.900	6117 58 9		L
ANT / 45 AL	aluminium painted	10	6.900	6117 59 1

Antenna socket

Single Socket Single Socket Modul 45 antenna socket.


Type	Colour	Pack, pc	Weight kg/% pc	Art. No.	Price €/pc	Discount group
ANT / 45-E	pure white	10	6.900	6117 61 1
ANT / 45-E	aluminium painted	10	6.900	6117 61 3

Antenna socket

Single socket

• TV: 5-68/120-862 MHz

•FM:87.5-108MHz

Connection damping 10 dB, supplied with terminal resistor.


Type	Colour	Pack, pc	Weight kg/% pc	Art. No.	Price €/pc	Discount group
ANT / 45-D	pure white	10	6.900	6117 60 0
ANT / 45-D	aluminium painted	10	6.900	6117 60 2

Antenna socket

tM CO

o o

LU _l _l

• TV: 5-68/120-862 MHz

• FM: 87.5-108 MHz

Connection damping 14 dB, connection of max. 4 TV sockets.

o o

3 o 3


Type	Colour	Pack, pc	Weight kg/% pc	Art. No.	Price €/pc	Discount group
TAE/45 6F	pure white	10	2.000	6117 42 8		L
TAE/45 6F	aluminium painted	10	2.000	6117 43 0		L

Telephone connection box

(fi CD Q

Telephone connection box Modul 45.

(fi O

CL LU

EGS 9
