| | | BETTERMANN | | |
| | | |
| | | The CNS...-D line protection device is an overvoltage protection device/fine surge network protection device, Type 3 (Class D) to DIN EN 61643-11 for the protection of consumers from transient overvoltages. | | |
| | | |
| | | The integrated protection circuit, consisting of gas dischargers and varistors is continuously monitored via a temperature controller manufacturer. In the arrester fails, the fault is signalled both audibly and visually. The mains voltage is maintained, even if the protection circuit fails. The protection devices are used as adapters in the versions with cold device connectors or multi-way connector manufacturer strip for connecting several terminals. | | |
| | | |
| | | Fine network protection/adapter with cold device connector | | |
| | | Arrester type 3 | | |
| | | |
| | | |
| | | | | | | | | | | | | | Type | Country- | Colour | Pack. | Weight | Item No. | | | | | specific | | | | | | | | | version | | | | | | | | | | | pes | kg/% pc | | | | | CNS-D-D | D | light grey | 1 | 30.000 | 5092 60 4 | | | | CNS-D-F | F | light grey | 1 | 30.000 | 5092 63 9 | | | | | | | | | | | | | |
| | | |
| | | Length ofconnection conductor: 1.5 m CNS-D: Surge protection device Type 3 (Class D) to VDE 0675 part 6-11 (DIN EN 61643-11), intended for use in protective contact plugs. • VDE-tested • With visual and acoustic signalling, function display • With cold unit connector • Length ofconnection conductor: 1.5 m • Y-circuit for high electrical safety Application: e.g. protection of PCs, printers, copiers, fax machines, etc. | | |
| | | |
| | | | | | | | | | | | | Maximum continuous voltage | Uc | V | CNS-D-D 255 | CNS-D-F 255 | | | | Requirement class to VDE 0675 Part 6-11 (DIN EN 61643-11) | | Type 3 | Type 3 | | | | Requirement class to IEC 61643-1 | | | class III | class III | | | | LPZ | | | 2-3 | 2-3 | | | | Nominal discharge current (8/20) | In | kA | 2.5 | 2.5 | | | | Maximum discharge surge current | Ima, | kA | 7 | 7 | | | | Nominal load current | Il | A | 10 | 10 | | | | Protection level (L-N / L/N-PE) | Up | V | <1000/<1500 | <1000/<1500 | | | | Response time | tA | ns | <25 | <25 | | | | | | | | | | | | |
| | | |
| | | CNS-D | | |
| | | |
| | | Fine network protection/socket strip | | |
| | | Arrester type 3 | | |
| | | |
| | | | | | | | | | | | | | Type | Country- | Colour | Pack. | Weight | Item No. | | | | | specific | | | | | | | | | version | | | | | | | | | | | pcs | kg/% pc | | | | | CNS 3-D-D | D | black | 1 | 65.000 | 5092 70 1 | | | | CNS 3-D-F | F | black | 1 | 65.000 | 5092 73 6 | | | | | | | | | | | | | |
| | | |
| | | CNS 3-D: Surge protection device Type 3 (Class D) to VDE 0675 part 6-11 (DIN EN 61643-11), intended for use in protective contact plugs. • With visual and acoustic signalling, function display • 3-way socket • Length of connection conductor: 2 m • Y-circuit for high electrical safety Application: e.g. protection of PCs, printers, copiers, fax machines, etc. | | |
| | | |
| | | | | | | | | | | | | Maximum continuous voltage | Uc | V | CNS 3-D-D 255 | CNS 3-D-F 255 | | | | Requirement class to VDE 0675 Part 6-11 (DIN EN 61643-11) | | Type 3 | Type 3 | | | | Requirement class to IEC 61643-1 | | | class III | class III | | | | LPZ | | | 2-3 | 2-3 | | | | Nominal discharge current (8/20) | In | kA | 2.5 | 2.5 | | | | Maximum discharge surge current | Ima, | kA | 7 | 7 | | | | Nominal load current | Il | A | 16 | 16 | | | | Protection level (L-N / L/N-PE) | Up | V | <1000/<1500 | <1000/<1500 | | | | Response time | tA | ns | <25 | <25 | | | | | | | | | | | | |
| | | o o Q. LU CO CN CU CSI _o E ni i¿ (h CO I- | | |
| | | |
| | | CNS-3-D | | |
| | | |
| | | |
| | | o | | |
| | | |
| | | 60 TBS | | |
| | | Always indicate the item number while ordering. | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
