BETTERMANN
FineController/network fine protection combined with SAT protection
Arrester type 3
Type
Country-
Colour
Pack.
Weight
Item No.
specific
version
pes
kg/% pc
FC-SAT-D
D
pure white
1
18.000
5092 81 6
T £z3 T
FC-SAT-D: Combined surge protection device Type 3 (Class D) to VDE 0675 part 6-11 (DIN EN 61643-11), intended for use on satellite systems and receivers.
• VDE-tested
• Separating device and function display
• Child lock
• Inc. 0.5 m connecting cable in white with F connectors (double-screen)
• Maximum continuous voltage SAT connection 72 V (DC)
• Frequency range 0-2400 MHz (75 ohm)
Note: the technical data in the table below refer to the energy supply.
Nominal voltage
Un
V
FC-SAT-D
230
Maximum continuous voltage
Uc
V
275
Requirement class to VDE 0675 Part 6-11 (DIN EN 61643-11)
Type 3
Requirement class to IEC 61643-1
class III
LPZ
2-3
Nominal discharge current (8/20)
In
kA
3
Voltage protection level
Up
kV
< 1,5
Nominal load current
Il
A
16
Maximum back-up industrial fuse
A
16
Response time
tA
ns
<25
FC-SAT-D
Arrester type 3
FineController/network fine protection combined with telephone protection
Type
Country-
Colour
Pack.
Weight
Item No.
specific
version
pcs
kg/% pc
FC-TAE-D
D
pure white
1
18.000
5092 82 4
Type I LPZ 3 I 2->3
FC-TAE-D: Combined surge protection device Type 3 (Class D) to VDE 0675 part 6-11 (DIN EN 61643-11), intended for use on telephone systems and terminal devices (fax, telephone, modem, NTBAs).
• VDE-tested
• Separating device and function display
• Child lock
• Inc. 0.5 m connecting cable in grey TAE/RJ 11
• Maximum continuous voltage TAE connection 200 V (DC)
Note: the technical data in the table below refer to the energy supply.
Nominal voltage
Un
V
FC-TAE-D
230
Maximum continuous voltage
Uc
V
275
Requirement class to VDE 0675 Part 6-11 (DIN EN 61643-11)
Type 3
Requirement class to IEC 61643-1
class III
LPZ
2-3
Nominal discharge current (8/20)
In
kA
3
Voltage protection level
Up
kV
< 1,5
Nominal load current
Il
A
16
Maximum back-up fuse
A
16
Response time
tA
ns
<25
o o
Q.
LU _l _l
FC-TAE-D
O
2
CD
CSI
o
ni
CO
I-
TBS 59
Always indicate the item number while ordering.
