| | | BETTERMANN | | |
| | | |
| | | CombiController - upper part | | |
| | | Arrester type 1+2 | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | Type | | Version | | Pack. | Weight | Item | No. | | | | | | | | pes | kg/% pc | | | | | | V 25-B+C/0-150 | 1-pole, | upper part; | 150V | 1 | 9.500 | 5097 | 08 8 | | | | V 25-B+C/0-280 | 1-pole, | upper part; | 280V | 1 | 9.500 | 5097 | 05 3 | | | | V 25-B+C/0-385 | 1-pole, | upper part; | 385V | 1 | 9.500 | 5097 | 06 1 | | | | | | | | | | | | | | | |
| | | |
| | | V 25-B+C/O...: CombiController - upper part. • Plug-in upper part can be mounted to base without tools and interrupting voltage | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | V 25-B+C/0-150 | V 25-B+C/0-280 | V 25-B+C/0-385 | | | | Maximum continuous voltage | Uc | V | 150 | 280 | 385 | | | | U max DC | Uc DC | V | 200 | 350 | 505 | | | | Requirement class to VDE 0675 Part 6-11 (DIN EN 61643-11) | | Type 1+2 | Type1+2 | Type 1+2 | | | | Requirement class to IEC 61643-1 | | | class l+ll | class l+ll | class l+ll | | | | LPZ | | | 0-2 | 0-2 | 0-2 | | | | Pulsed current (10/350) | limp | kA | 8 | 7 | 7 | | | | Nominal discharge current (8/20) | In | kA | 30 | 30 | 30 | | | | Maximum discharge surge current | Imax | kA | 50 | 50 | 50 | | | | Voltage protection level | Up | kV | < 0,6 | < 0,9 | <1,5 | | | | Response time | tA | ns | <25 | <25 | < 25 | | | | | | A | 160 | 160 | 160 | | | | Temperature range | e | °C | -40 - +80 | -40 - +80 | -40 - +80 | | | | Protection rating | | | IP 20 | IP20 | IP20 | | | | Division unit TE (17.5 mm) 1 | 1 | 1 | | | | | | | | | | | | | |
| | | V 25-B+C/0 | | |
| | | |
| | | |
| | | | | | | | | | | | | Type | Version | Pack. | Weight | Item No. | | | | | | pcs | kg/% pc | | | | | C 25-B+C/0 | 1-pole, upper part; 255V | 1 | 5.195 | 5095 60 3 | | | | | | | | | | | | |
| | | |
| | | upper part C 25-B+C/..+NPE: Plug-in total discharge gap for use between neutral lines (N) and protector (PE). Suitable for use in combination with: • CombiController Type V 25-B+C • SurgeController Type V 20-C | | |
| | | |
| | | | | | | | | | | | | | | | | | | C 25-B+C/0 | | | | Maximum continuous voltage | Uc | V | 255 | | | | Requirement class to VDE 0675 Part 6-11 (DIN EN 61643-11) | | Type 1+2 | | | | Requirement class to IEC 61643-1 | | | class l+ll | | | | LPZ | | | 0-2 | | | | Pulsed current (10/350) | Iimp | kA | 25 | | | | Maximum discharge surge current | Imax | kA | 50 | | | | Voltage protection level | Up | kV | <1,2 | | | | Response time | tA | ns | <25 | | | | Temperature range | e | °C | -40 - +80 | | | | Protection rating | | | IP 20 | | | | Division unit TE (17.5 mm) 1 | | | | | | | | | | | |
| | | C 25-B+C/0+NPE | | |
| | | |
| | | |
| | | o o Q. LU _l _l | | |
| | | |
| | | 2 | | |
| | | |
| | | CD | | |
| | | |
| | | tM o ni CO | | |
| | | |
| | | TBS 41 | | |
| | | Always indicate the item number while ordering. | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
