Installation examples:Ceiling and wall supports LHS, MHS and SHS

LHS 5 KMounting on anchor rail LHS 5 K Mounting on steel girder with clamping lug KL 1 LHS 5 K Mounting on steel girder with clamping angle KWH and rail. Cable routing parallel to steel girder LHS 5 K Mounting on steel girder with clamping angle KWH and rail. Cable routing across steel girder LHS5 K, LKA One-sided bracket mounting LHS 5 K, LKA Two-sided bracket mounting LHS 5 K, LKA Two-sided offset bracket mounting LHS 5 K Ceiling mounting with anchors
