| | | OBO BETTERNIANN Truss-head bolts | | |
| | | |
| | | | | | | | | | | | | Type | Dim. mm | Pack. qty | Weight kg/100 | Ord. no. F/G | | | | 12510 K12 | M6 x 12 | 100 | 0.656 | 640613 0 | | | | | | | | | | | | |
| | | Steel, hot-dip galvanised to DIN 267 Part 10 Steel, electro-galvanised | | |
| | | F G | | |
| | | |
| | | |
| | | |
| | | Complete with hexagon head combination nuts (nuts with press-fit washers) Truss-head bolts | | |
| | | |
| | | | | | | | | | | | | | Type | Dim. | Quality | Pack. | Weight | Ord. no. | | | | | | | qty | kg/100 | F | | | | | | | | | | | | | FRS/M 6x12 | M 6 x 12 | 5.6 | 100 | 0.680 | 6406 90 4 | | | | FRS/M 6x16 | M 6 x 16 | 5.6 | 100 | 0.700 | 6406 89 0 | | | | FRS/M 6x20 | M 6 x 20 | 5.6 | 100 | 0.780 | 6406 88 2 | | | | FRS/M 8x16 | M 8 x 16 | 5.6 | 50 | 1.900 | 6406 92 0 | | | | FRS/M 8x16S | M 8 x 16 S | 5.6 | 50 | 1.900 | 6406 93 9 | | | | FRS/M 8x16 | M 8 x 16 | 8.8 | 50 | 1.900 | 6406 96 3 | | | | FRS/M 8x20 | M 8 x 20 | 5.6 | 50 | 2.100 | 6406 97 1 | | | | FRS/M 8x25 | M 8 x 25 | 8.8 | 50 | 2.270 | 6406 99 8 | | | | FRS/M 8x35 | M 8 x 35 | 5.6 | 50 | 2.550 | 6407 04 8 | | | | FRS/M10 x 20 | M10 x 20 | 5.6 | 50 | 3.880 | 6407 47 1 | | | | FRS/M10 x 25 | M10 x 25 | 5.6 | 50 | 4.140 | 6407 52 8 | | | | FRS/M10 x 25 | M10 x 25 | 8.8 | 50 | 4.140 | 6407 56 0 | | | | FRS/M10 x 30 | M10 x 30 | 8.8 | 50 | 4.400 | 6407 57 9 | | | | FRS/M12 x 25 | M12 x 25 | 5.6 | 25 | 5.800 | 6406 25 4 | | | | FRS/M12 x 30 | M12 x 30 | 5.6 | 25 | 6.200 | 6406 27 0 | | | | | | | | | | | | | |
| | | |
| | | Complete with hexagon nut and washer | | |
| | | Steel, hot-dip galvanised to DIN 267 Part 10 | | |
| | | F | | |
| | | |
| | | |
| | | |
| | | | | | | | | | | | | Type | Dim. | Pack. qty | Weight kg/100 | Ord. no. F | | | | 12510 A 25 S | M10 x 25 | 50 | 4.200 | 6407 53 6 | | | | | | | | | | | | |
| | | |
| | | Complete with hexagon nut and washer With small head for bracket series TPS Washer | | |
| | | Steel, hot-dip galvanised to DIN 267 Part 10 | | |
| | | F | | |
| | | |
| | | |
| | | |
| | | | | | | | | | | | | Type | For bolts with thread | Pack. qty | Weight kg/100 | Ord. no. G | | | | 966 | M12 | 100 | 0.627 | 340212 6 | | | | | | | | | | | | |
| | | |
| | | Steel, electro-galvanised to DIN 125 A | | |
| | | G | | |
| | | |
| | | |
| | | Drive-in tie-bolts | | |
| | | |
| | | | | | | | | | | | | | Type | Thread | Screw depth min.-max. mm | Pack. qty | Weight kg/100 | Ord. no. G | | | | FZEA 10 x 40 FZEA 12 x 40 FZEA 14 x 40 | M8 M10 M12 | 11 - 17 13 - 19 15 - 21 | 100 100 50 | 1.550 2.075 2.750 | 3492 03 6 3492 06 0 3492 09 5 | | | | | | | | | | | | | |
| | | o' | | |
| | | |
| | | |
| | | Anchor for low loads in steel design. Approval no.: Z-21.1-958 | | |
| | | |
| | | 92 | | |
| | | Please always state the ordering number when ordering. | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
