OBO

BETTERNIANN

Hammer-head bolts

lo

CD


	Type	Dim.	Quality	Pack.	Weight	Ord. no.
		mm		qty	kg/100	F

	5022	M 6 x 25	4.6	50	1.960	1151 01 0
	5022	M 6 x 30	4.6	50	1.992	1151 02 9
	5022	M 6 x 40	4.6	50	2.140	1151 04 5
	5022	M 8 x 25	4.6	50	2.150	1151 21 5
	5022	M 8 x 30	4.6	50	2.990	1151 22 3
	5022	M 8 x 40	4.6	50	3.600	1151 25 8
	5022	M10 x 25	4.6	50	4.360	1151 40 1
	5022	M10 x 30	4.6	50	4.580	1151 42 8
	5022	M10 x 40	4.6	50	5.070	1151 44 4

_

Complete with 1 washer and 1 nut


	Type	Dim. mm	Quality	Pack. qty	Weight kg/100	Ord. no. G
	5022 5022	M12 x 30 M12 x 40	4.6 4.6	25 25	6.130 6.900	1151 62 2 1151 64 9

Suitable for:

Profile rails 1268 SL see page 82 F Steel, hot-dip galvanised to DIN 267 Part 10

1268 ^S/SL ^see ^page ⁸³ g Steel, electro-galvanised

Hammer-head bolts

32

B


	Thread	B	H
	D	mm	mm
	M10	11	9.5
	M12	13	10.5

Type

Dim. mm

Quality

Pack. qty

Weight Ord. no. kg/100 G


	5023	M10 x 30	5.6	50	4.130	1153 41 2
	5023	M10 x 35	5.6	50	4.690	1153 42 0
	5023	M10 x 40	5.6	25	4.970	1153 43 9
	5023	M12 x 30	5.6	25	6.450	1153 61 7
	5023	M12 x 35	5.6	25	6.800	1153 62 5
	5023	M12 x 40	5.6	25	7.200	1153 63 3
	5023	M12 x 50	5.6	25	7.840	1153 641

Complete with 1 washer and 1 nut

Complete with 1 nut and washer For profile rails type CPS 4 G

G Steel, electro-galvanised

88

Please always state the ordering number when ordering.
