Installation examples:Profile rails, angle profiles

1268/KPHead plate as wall mounting 1268/KP Suspended structure with gusset plate and head plate 1268/KP Ceiling mounting 1268/W 90 Suspended structure with mounting bracket and head plate 1268/KD Mounting variant gusset plate 1268/KD Gusset plate mounting 1268/KD Gusset plate with turned rail 1268/W 90 Variant with mounting bracket 328 Flange clamps and C-rail on girder profile 1268/SK Protective cap mounting 12130 Double suspension WE 40/65 Double suspension WEK SR End cap mounting KVZ 375 Electrolytic corrosion protectionClean the damagedarea carefully toremove dirt, grease, zinc oxide or corrosion products, rust, zincoxide as a combustionproduct of zinc from welding, and depositsof welding spatter.
KTS_GB_V0_11032002 Please always state the ordering number when ordering.
