Head plate

56 11
20 150 120 Type Pack.qty Weightkg/pc Ord. no. FT
100 ~103 25 1268/KP 25 0.420 6350054 9 FT Steel, hot-dip galvanised to DIN EN ISO 1461

Gusset plate

100 9 37.5 25
Type Pack.qty Weightkg/pc Ord. no. FT 100 1268/KD 25 0.220 6350100 FT Steel, hot-dip galvanised to DIN EN ISO 1461

Mounting bracket 90 °

3 30
102~ 102~
Type Pack.qty Weightkg/pc Ord. no. G 25 5 1268/W 90 25 0.110 6350151 G Steel, electro-galvanised
KTS_GB_V0_11032002

84

Please always state the ordering number when ordering.
