Installation examples:Wall brackets MWA, AW .., AWV, support bracket AS ..

MWA 12Wall mounting with anchor AW 15 Wall mounting with anchor AW 15 Anchor rail mounting AW 30 Girder mounting, welded AW 30 Girder mounting, bolted AWV Use in tunnel constructions AWV Mounting on inclined walls AWV Mounting on inclined walls AS 30 Wall mounting with TS 4 support AS 30 Wall mounting with IS 8 K support AS 30 Mounting on IS 8 K support AS 15 Mounting on TS 4 support AS 55, IS 8 K Bracket mounting/floor support US 7 K, AW 55 Two-sided bracket mounting to US 7 K support with bolt 12530/110 and spacer 11500/61
KTS_GB_V0_11032002 Please always state the ordering number when ordering.
