Adapter head plate, symmetrical
50 140 13 x 5013 x 35
100 320 400 Adapter head plate for IS 8K and US 7K supportsThe adapter head plate is used to increase the load-bearing capacity of IS 8K and US 7K supports, taking into account anchor ratings.Due to the simple design, it can be used flexibly and economically on site.A decision on its use can be made quickly on site, depending on the actualload applied.For further load data see page 433
Type Pack.qty Weightkg/pc Ord. no. FT KA-SY 1 2.800 6346804 FT Steel, hot-dip galvanised to DIN EN ISO 1461
Head plate
200 140 13 x 30
70 100 25 50 150 50 25 11 5 15 17.5
Type Pack.qty Weightkg/pc Ord. no. FT For mounting on horizontal concrete ceilings and steel girders, bolts onto IS 8 supports, max. length: 2000 mm, can also be used on steel girderswith flange widths approx 90-140 mm running parallel to cable routes
For larger flange widths, use C rails and clamping angles. KI 8 10 1.550 6347053 Complete with 2 bolts FRS M10 x 25 FT Steel, hot-dip galvanised to DIN EN ISO 1461 200 140 13 x 30
11 x 15
70 100 25 50 150 50 25 68
Type Pack.qty Weightkg/pc Ord. no. FT For mounting on horizontal concrete ceilings and steel girders, bolts onto IS 8 supports, max. length: 2000 mm, can also be used on steel girderswith flange widths approx 90-140 mm crossing cable routesFor larger flange widths, use C rails and clamping angles. KI 8 NOK 10 1.630 6347061 Complete with 2 bolts FRS M10 x 25 FT Steel, hot-dip galvanised to DIN EN ISO 1461
KTS_GB_V0_11032002 66
Please always state the ordering number when ordering.
