OBO

BETTERMANN

Support brackets

110


	Type	Length	Height
		mm	mm
	AS 30/11	110	60
	AS 30/16	160	65
	AS 30/21	210	70
	AS 30/31	310	80
	AS 30/41	410	80
	AS 30/51	510	90
	AS 30/56	560	100
	AS 30/61	610	100

O O C3 I

160

t

210

310

x

7 x 47 7 x 35

410


	Type	Length	Pack.	Weight	Ord. no.
		mm	qty	kg/pc	FT

	AS 30/11	110	30	0.300	6418 75 9
	AS 30/16	160	30	0.370	6418 76 7
	AS 30/21	210	25	0.440	6418 77 5
	AS 30/31	310	25	0.780	6418 79 1
	AS 30/41	410	20	1.000	6418 81 3
	AS 30/51	510	10	1.400	6418 84 8
	AS 30/56	560	10	1.550	6418 85 6
	AS 30/61	610	10	1.680	6418 86 4

510

610

For mounting on TS 4 and IS 8 supports The bracket height is fully adjustable. Perm. load F in kN: 3.0 For further load data see page 433

FT Steel, hot-dip galvanised to DIN EN ISO 1461

210


	Type	Length mm	Height mm
	AS 55/21	210	90
	AS 55/31	310	110
	AS 55/41	410	130
	AS 55/51	510	145
	AS 55/56	560	165
	AS 55/61	610	165
	AS 55/71	710	195
	AS 55/81	810	195

100 50 75 37.5

-f-

□

⁷ ^x ³⁵ 410 co t

510

610

710


	Type	Length	Pack.	Weight	Ord. no.
		mm	qty	kg/pc	FT

	AS 55/21	210		0.810	6419 04 6
	AS 55/31	310		1.330	6419 06 2
	AS 55/41	410		1.730	6419 08 9
	AS 55/51	510		2.330	641910 0
	AS 55/56	560		2.600	641911 9
	AS 55/61	610		2.830	6419 12 7
	AS 55/71	710		3.850	6419 14 3
	AS 55/81	810		4.440	6419 17 8

810

<5

For mounting on TS 4 and IS 8 supports The bracket height is fully adjustable. Perm. load F in kN: 5.5 For further load data see page 433

o o o¹m

FT Steel, hot-dip galvanised to DIN EN ISO 1461

65

Please always state the ordering number when ordering.
