Installation examples:Ceiling, floor and wall supports US 5 and US 7

US 5 KCeiling mounting US 5 K Mounting on steel girder with clamping angle KWS Cable routing parallel to steel girder US 5 K Mounting on steel girder with clamping angle KWH and rail CPS 5.Cable routing parallel to steel girder US 5 K, AW 15One-sided bracket mounting with bolt 12530/80 and spacer 11500/45 KUS 5 Mounting on US 5 support with bolt 12530/80 and spacer 11500/45 US 5, VUS 5 Support connection using VUS 5 US 7 K Ceiling mounting US 7 K Mounting on anchor rail US 7 K Mounting on steel girder with clamping angle KWS Cable routing parallel to steel girder, max. flangewidth 140 mm US 7 KMounting with clamping angle and rail Cable routing parallel to steel girder US 7 K Mounting with clamping angle and rail Cable routing across steel girder US 7 K Suspension from ceiling US 7 K, AW 55 One-sided bracket mounting with bolt 12530/100 US 7 K, AW 55 Two-sided bracket mounting to US 7 K support with bolt 12530/110 US 7 K, KA-SY Mounting symmetrical adapter head plate KA-SY
