Head plate, variable

200 140 13 x 30
100 130 50 Type Pack.qty Weightkg/pc Ord. no. FT
13 40
20 KU 7 VQP 1 1.660 6349153 1 spacer 45 mm long and 2 hexagon head bolts M12 x 80 must be ordered separately For mounting on inclined and horizontal concrete ceilings and steel girders, for U supports, max. length: 2000 mm FT Steel, hot-dip galvanised to DIN EN ISO 1461

Hexagon head bolt

Type Dim.mm Pack.qty Weightkg/pc Ord. no. F 12530/90 M10 x 90 20 0.018 6418252 Complete with hexagon nut, 2 washers and 1 serrated lock washer F Steel, hot-dip galvanised to DIN 267 Part 10

Spacer

40 45 80
Type Pack.qty Weightkg/pc Ord. no. FT DSK 61 20 0.130 6416519 As insert in US 7 supports with head plate KU 7 VQP FT Steel, hot-dip galvanised to DIN EN ISO 1461
KTS_GB_V0_11032002

60

Please always state the ordering number when ordering.
