OBO

BETTERMANN

U supports


	0 0 0 0 n	_i
	U ~n

o

of

4


	Type	Length	Pack.	Weight	Ord. no.
		mm	qty	kg/pc	FT

	US 7/20	200		0.800	6340 01 6
	US 7/30	300		1.200	6340 03 2
	US 7/40	400		1.600	6340 05 9
	US 7/50	500		2.000	6340 07 5
	US 7/60	600		2.400	6340 09 1
	US 7/70	700		2.800	6340 11 3
	US 7/80	800		3.200	634014 8
	US 7/90	900		3.600	6340 16 4
	US 7/100	1000		4.000	6340 18 0
	US 7/150	1500		6.000	6340 23 7
	US 7/200	2000		8.000	6340 29 6
	US 7/300	3000		12.000	6340 37 7
	US 7/600	6000		24.000	6340 31 8

For mounting on concrete walls and masonry, horizontal and inclined concrete ceilings and steel girders

For load data see page 429

FT Steel, hot-dip galvanised to DIN EN ISO 1461

U support connector manufacturer

0 0 0

CD CD CD

o o

C\l

o

LO

to

C\l

CO

26

13


	Type	Pack. qty	Weight kg/pc	Ord. no. FT
	VUS 7	10	1.100	6018 37 8

LO

61

o o

o

o'

to

For connection of US 7/... supports FT Steel, hot-dip galvanised to DIN EN ISO 1461

Complete with 6 truss-head bolts M12 x 25 mm

55

Please always state the ordering number when ordering.
