U supports

200

13 x 30


	0 n
	u 0 0	_l 1
	0 "0	0 LO


Type	Length	Pack.	Weight	Ord. no.
	mm	qty	kg/pc	FT

US 7 K/20	200		1.740	6339 01 8
US 7 K/30	300		2.140	6339 03 4
US 7 K/40	400		2.540	6339 05 0
US 7 K/50	500		2.940	6339 07 7
US 7 K/60	600		3.340	6339 09 3
US 7 K/70	700		3.740	6339 11 5
US 7 K/80	800		4.140	633913 1
US 7 K/90	900		4.540	633916 6
US 7 K/100	1000		4.940	633918 2
US 7 K/110	1100		5.340	633919 0
US 7 K/120	1200		5.740	6339 20 4
US 7 K/130	1300		6.140	6339 21 2
US 7 K/140	1400		6.540	6339 22 0
US 7 K/150	1500		6.940	6339 23 9
US 7 K/160	1600		7.340	6339 24 7
US 7 K/170	1700		7.740	6339 25 5
US 7 K/180	1800		8.140	6339 26 3
US 7 K/190	1900		8.540	6339 27 1
US 7 K/200	2000		8.940	6339 29 8

Welded head plate

For mounting on horizontal concrete ceilings, steel girders approx 90 -140 mm flange width, directly with clamping angles type KWS, wide flange girders with C rail and clamping angles type KWH

Bracket adjustable via holes.


Type	B 200 F in kN	B 400 F in kN	B 600 F in kN
US7 K/20	8.3	5.0	3.5
US7 K/30	8.3	5.0	3.5
US7 K/40	8.3	5.0	3.5
US7 K/50	8.3	5.0	3.5
US7 K/60	8.3	5.0	3.5
US7 K/70	8.3	5.0	3.5
US7 K/80	8.3	5.0	3.5
US7 K/90	8.3	5.0	3.5
US7 K/100	8.3	5.0	3.5
US7 K/110	8.3	5.0	3.5
US7 K/120	8.3	5.0	3.5
US7 K/130	8.3	5.0	3.5
US7 K/140	8.3	5.0	3.5
US7 K/150	8.3	5.0	3.5
US7 K/160	7.5	4.2	2.9
US7 K/170	7.5	4.2	2.9
US7 K/180	7.5	4.2	2.9
US7 K/190	7.5	4.2	2.9
US7 K/200	7.5	4.2	2.9

Perm. load:

With welded head plate

For correct wall bracket AW 30/... see page 57 and AW 55/... see page 57

For further load data see page 429

FT Steel, hot-dip galvanised to DIN EN ISO 1461

End cap

74.5


Type	Colour	Pack.	Weight	Ord. no.
	mm	qty	kg/pc	PE
US 7 KS	yellow	20	0.018	6338 49 6

PE Polyethylene, yellow (RAL 1016)

Please always state the ordering number when ordering.
