O/E/N 26 MINIATURE HIGH POWER RELAY Sensitive Version Low Height Direct PCB type Dust Protected / Sealed Contact Arrangement 1C,2C,1CK Contact Material : AgNi Contact Rating 1 Form C : 10 A 2 Form C : 8 A 1 Form C K-tpe : 16 A Rated Voltage :230VAC / 24VDC Max. Switching Voltage :440VAC / 125VDC Max. Switching Current : 10 A (1C), 5 A (2C) : 16 A (1CK) 6 4.2 90 Contact Resistance Initial : 100 m Ohms 12 8.4 360 Nominal Coil Power : 0.4 W 24 16.8 1440 Operating Power : 0.2 W 110 77 25200 Life Expectancy Mechanical : 1 x 107 operations Electrical : 1 x 105 operations Dielectric Strength 1 C Between coil and contacts : 5000VAC Between Open contacts : 1000VAC 1CK Insulation Resistance : 1000Meg.Ohms @ 500 VDC,250C, RH 50 2C Operate time at nom. Volt : 15 milli sec max Release time at nom. Volt : 8 milli sec max Ambient Temperature : -40oC to + 85o C Weight : 14 g 1 Form C(K) / 2 Form C 1 Form C(K) / 2 Form C O/E/N India Ltd DRILLING PATTERN Typical Applications All dimensions are in mm. Specifications subject to change without notice. Industrial Electronics, UPS, Office Automation, Home Appliances 1 Form C DIMENSIONS SPECIFICATIONS COIL DATA HOW TO ORDER Coil Resistance Ohms+10% Nominal Voltage (VDC) Pick-up Voltage (VDC) 1 Form C CIRCUIT DIAGRAMS
