MEDICAL VACUUM
TYPICAL DIAGRAM (triplex version, electronic control, horizontal configuration)VACUUM PUMPS: rotary vanes type, with closed circuit oil lubrication,
6 =
100% work load capacity, cooling
7
radiator, direct coupled to the IP55
> electric motor. Delivered with non
; 8
return valve, high efficiency separator.
: 9
BACTERIAL FILTRATION LINE:
7
single and duplex version are available. Each filtration line is equipped with
6
vacuum pump a translucent drain jar, a bacterial
7
steel receiver filter with visible level, and an isolation line (by-pass).
8
control panel
9
electrical and emergency control panel
:
CONTROL PANEL: the bacterial filtration line
;
exhaustion drain jar standard "Electromatic" ™
oil drain collector panel (electromechanical
=
suction flexible hose type), equipped as standard
>
exhaustion collector control device, features all required control and alarm (local and remote) devices. RECEIVERS: they are delivered fully equipped, with all As an option, the "Supervisor" ™ (with Micro CPU), control and security accessories. Horizontal, vertical, extends the available features, particularly with galvanized and high pressure versions available upon maintenance alarms and advanced automatic request. regulation modes.
The NOVAIR range: available medical vacuum stations, main technical data (single, duplex, triplex sources). Flow Medical vacuum station type Noise level Motor(s) power Feeding capacity Average data*
(m 3 /h) (dB(A)) (kW) 50 Hz
60 Hz 50 Hz
60 Hz 50 Hz
60 Hz (number of medical beds) 1013
1216 S-RT, D-RT, T-RT 1000 80
81 22
30 765
918 S-RT, D-RT, T-RT 750 79
80 18.5
22 536
643 S-RT, D-RT, T-RT 540 79
80 11
15 preset vacuum level: -600 / -900 mbar 403
484 S-RT, D-RT, T-RT 400 78
79 7.5
11 1000 beds 300
350 S-RT, D-RT, T-RT 300 72
73 5.5
7.5 800 205
245 S-RT, D-RT, T-RT 205 70
71 4
5.5 600 152
182 S-RT, D-RT, T-RT 160 71
72 3
4 400 105
126 S-RT, D-RT, T-RT 106 67
69 2.2
3 200 65
78 S-RT, D-RT, T-RT 065 69
70 1.5
2.2 150 45
54 S-RT, D-RT, T-RT 045 68
69 1.1
1.5 100 35
42 S-RT, D-RT, T-RT 035 65
66 0.75
1.1 85 20
24 S-RT, D-RT, T-RT 020 67
68 0.55
0.65 65 17
20 S-RT, D-RT, T-RT 017 59
60 0.55
0.75 50 12
14 S-RT, D-RT, T-RT 012 60
62 0.55
0.55 40 5
5 S-RT, D-RT, T-RT 005 51
51 0.29
0.32 20 beds
*Please refer to us for any specific inquiry. It will be our pleasure to give you details about the required medical vacuum station, accordin g to the relevant standards and to the hospital's piping data. NOVAIR S.A.S. x 6 RUE PAUL LANGEVIN x 93270 SEVRAN x FRANCE x TEL.: (+33) 01 43 84 94 83 x FAX: (+33) 01 43 84 87 40 x WWW.NOVAIR.FR
