Uni-Chem™ Composite Hoses Marine Service Applications All Uni-Chem™ hose styles are constructed to marine service specifications in accordance with U.S. Coast Guard spec. 154.500 and I.M.O. regulations. DISTRIBUTOR STAMP Dry Break Couplings Safety Breakaway Couplings Uni-Chem™ Disclaimer It is impossible to test Uni-Chem™ hose under all conditions to which it might be subjected in the field. It is therefore the buyer and/or end user’s responsibility to test all Uni-Chem™ hose under conditions that duplicate the service condition prior to installation. UNI-FLON™ AND UNI-OIL™ COMPOSITE HOSES Uni-FLON™ and Uni-OIL™ high temperature composite hoses provide optimum chemical resistance, strength and versatility needed to get the job done. Superior Performance From The Inside Out Uni-Chem™ composite hoses are made only with carefully selected materials throughout. Their inner films and fabrics provide optimum chemical resistance against today's highly aggressive media. Protected with the toughest PVC impregnated outer covers, Uni-Chem™ composite hoses provide the strength and versatility needed to get the job done. UNI-CHEM™ COMPOSITE HOSES Versatile End Configurations Only Uni-Chem™ offers uniformly crimped hose ends (1"- 8" I.D.). Combined with our custom tooled end fittings Uni-Chem™ provides a leak free hose assembly every time. Male NPT Ends: Carbon Steel, 316L Stainless Steel, Aluminum, Polypropylene Flanged Ends: TTMA flanges for Bottom Loading Hoses. Fixed or floating in Carbon Steel, 304 and 316 Stainless Steel, and Aluminum Cam and Groove: Quick disconnect couplings in 304 Stainless Steel, and Aluminum Dry Break Couplings Todo Self Sealing Couplings: Provide for the safe transfer of potentially hazardous chemicals. Todo self sealing couplings employ proven valve technology that automatically stops the flow with zero product spillage. Safety Breakaway Couplings An economical solution to costly accidental driveaways. The Todo SBC provides a lightweight full- flow means to prevent hard piping and loading arm damage. Available with female NPT threaded or ANSI 150 lb. flanged ends. Inner Helix Polypropylene Inner Fabric and Films Vapor Barrier Films Reinforcing Fabric PVC-impregnated Nylon Cover and Outer Helix Uni-FLON™ HT Composite Hose Novaflex Uni-FLON™ HT is designed as an upgraded version of Novaflex’s standard Uni-FLON™, except that it has a temperature rating of 350°F (177°C). The high temperature version has the same Teflon® tube but the reinforcement elements have been upgraded to polyamides and nylons that have superior strength at elevated temperatures permitting the 250 psi working pressure to be maintained. Uni-OIL™ 250 HT High Temperature Composite Hose Novaflex Uni-OIL™ 250 HT is a high temperature version of the standard Uni-OIL™ petroleum. This high temperature hose can handle maximum operating temperatures of 300°F. The hose design uses a composite of temperature resistant materials and is rated for use with a wide range of petroleum products. INS* ID 1 1.5 2 3 4 OUT* ID 1.5 2.0 2.5 3.5 4.5 Max WP PSI 250 250 250 250 250 Burst Pres PSI 1000 1000 1000 1000 1000 Bend Rad. Inches 4.1 5.9 7.8 11.1 14.2 Weight LB/FT .6 .8 1.6 2.4 3.2 Max Lengths 100 100 100 100 100 Plies 2 2 2 2 2 INS* ID 1 1.5 2 3 4 OUT* ID 1.5 2.0 2.5 3.5 4.5 Max WP PSI 250 250 250 250 250 Burst Pres PSI 1000 1000 1000 1000 1000 Bend Rad. Inches 4.1 5.1 6.1 8.2 14.0 Weight LB/FT .65 .85 1.7 2.6 3.4 Max Lengths 100 100 100 100 100 Operating Temperature -40ºF to +350ºF / -40ºC to +177ºC Operating Temperature -40ºF to +300ºF / -40ºC to +148ºC New Jersey 1024 Industrial Drive West Berlin, NJ 08091 Telephone: (856) 768-2275 Toll-free: 1-800-225-0215 Fax: (856) 768-2385 North Carolina 449 Trollingwood Road Haw River, NC 27258 Telephone: (336) 578-2161 Toll-free: 1-800-334-4270 Fax: (336) 578-5554 IN USA Indianapolis, Indiana 7812 Moller Road Indianapolis, Indiana 46268 Telephone: (317) 334-1444 Toll-free: 1-800-526-6288 Fax: (317) 334-1535 Whitby, Ontario 119 Consumers Drive, Whitby, Ontario L1N 1C4 Telephone: (905) 666-4970 Fax: (905) 666-9388 IN CANADA Bromborough, Wirral 18 Candy Park 2, Power Road Bromborough, Wirral UK CH62 3QT Telephone: 44(0)151-334-0873 Fax: 44(0)151-334-7145 Email: sales@novaflex.co.uk Web: www.novaflex.co.uk IN U.K. ™ ® Email: sales@novaflex.com Website: www.novaflex.com ™ ® ™ ® NO902 09/2010 NO902_BIOCHEM BROCH_FINAL.indd 1 9/27/10 10:22:02 PM
