® Industrial Duct Products

1 NovaFlex general service ducts are extremely lightweight, flexible and economical. GENERAL SERVICE DUCTS U-LOK 100 An extremely flexible duct with good low temperature resistance and chemical resistance. Manufactured with UL94V-0 approved materials. Applications Dust control Air handling Light material handling Fume control Construction Product code: 3UL100X Material: Polyester fabric, Neoprene coated Construction: Mechanical bond, corrosion resistant helix Diameters: 2” to 24” Bend radius: =1.5 x I.D. Weight: 6” I.D. =.9 lbs/ft. Standard length: 25 ft Compression Ratio: 6:1. Temperature Range:...

2 Available in metric sizes AF-1 With a bonded construction and encapsulated wire this duct is non-marking lightweight and economical. Manufactured with UL94V-0 approved materials. Applications Air handling Fume control Dust collection Cool air supply Construction Product code: 3ULAFIX Material: Polyester fabric, Neoprene coated Construction: Single ply fabric over fully encapsulated spring steel helix Diameters: 1.5” to 36”. Weight: 6” I.D. =.84 lbs/ft. Length: 25 ft. Compression Ratio: 5:1. Temperature Range: -40°F (-40°C) to +250°F (121°C) Colour: Black I.D. 2 3 4 5 6 8 10 12 Working Pressure/PSI...

3 Available in metric sizes U-LOK 200 Heavier gauge fabric and coating to provide longer service life. Neoprene coating provides good cold temperature resistance compared with PVC. Manufactured with UL94V-0 approved materials. Applications Heavy-duty dust control Outdoor plant clean-up Sawdust, hot air blower Construction Product code: 3UL200X Material: polyester/neoprene Construction: mechanical bond, corrosion resistant helix Diameters: 3” to 24” I.D. Larger sizes available Bend radius = 1.5 x I.D Weight: 6” I.D. = 1.1 lbs/ft Length: 25ft Compression ratio 6:1 Temperature range: -65°F (-54°C)...

4 ® Available in metric sizes AF-2WS Double ply bonded construction coupled with a scuff guard for additional external abrasion resistance. Manufactured with UL94V-0 approved materials. Applications Particle control Pellet and chip handling Areas of high vibration Large volume fume control Construction Product code: 3ULAF2Y Material: Polyester/Neoprene coated. Black with yellow or black bonded wear strip. Construction: Two ply fabric over fully encapsulated spring steel wire helix. Diameters: 1.5” to 36” Weight: 6” I.D. =1.02 lbs/ft. Length: 25 ft Compression Ratio: 1.5:1 Temperature Range: -40°F...

5 Available in metric sizes U-Lok 1010 & U-Lok 1020 A clear duct designed for flexibility with excellent abrasion resistance. Clear wall for flow monitoring. External metallic helix for scuff resistance. Available in two gauges manufactured with12 mil and 20 mil. Applications Extremely flexible Ideal for use with articulating equipment Compressible, saw dust control In plant clean up (FDA approved material) Construction Product code: 3UL1010 3UL1020 Material: Urethane, 12 mil, clear. (style U-Lok 1010) or 20 mil, clear (style 1020) Construction: Mechanical lock, corrosion resistant helix Diameters:...

6 ® SF –TPR –DC (Duct Cleaning) Crush resistant duct with excellent shape retention. Extremely flexible and compressible. Enhanced chemical resistance of TPR with an extremely smooth interior for superior flow. Heavy duty external wear strip protects against abrasion - but will not scuff or mark surfaces. No wire. Applications Industrial and residential duct cleaning. In-plant dust control; shop vacuum systems. Chemical fume control. Construction Product code: 9SFTPRX_DC Material: 0.045” extruded thermo plastic rubber Diameters: 3” to 10” Temperature range: -60°F to +250°F. Weight: 1.8 lbs -...

7 U-Lok 1000* A highly flexible duct made of a fine wire reinforced (E-Glass ceramic cloth) that is chemically treated and coated. Ideal for higher temperature fume recovery. Applications High temperature fume recovery Scuff resistant Flame resistant *Air Velocity should be less than 50 m/sec. *Not recommended for diesel fume applications Construction Product code: 3UL1000 Material: Alumina coated, textile glass, fabric reinforced with a fine V4A wire. Construction: Mechanical bond, galvanized steel helix (also available stainless steel helix). Diameters: 3” to 24” I.D. Larger sizes available....

8 ® I.D. 4 5 6 8 10 12 Working Pressure/PSI 3.7 3 2.3 1.4 1 .75 Negative Pressure Inch. H.g 2.1 1.6 1.2 .7 .45 .3 ultra high temperature applications. can be incorporated downstream from the heat and fume source. temperature exhaust ducting for lower velocity applications up to 500°F constant flexing applications in single and double ply styles. I.D. 2 3 4 5 6 8 10 12 Working Pressure/PSI 50 45 40 35 30 15 8 4 Negative Pressure Inch. H.g 20 14 10 8 6 6 4 4 Silicone Nomex® Duct For use with hose reels 2 ply silicone nomex exhaust extraction duct offers the added strength and durability required...

9 Ultra flexible lightweight ducts designed specifically for industrial chemical fume control applications U-Lok 500 This nylon polyamid duct provides good chemical resistance at an affordable price. With an excellent gas permeability rating this product is ideal for containing noxious odors and gases. Applications Chemical fume control Clean room Visual monitor, sight gauge Painting Laboratory Construction Product code: 3UL500X Material: Nylon/Polyamid (clear) Construction: Mechanical bond, corrosion resistant helix Diameter: 3” to 24” I.D. Larger sizes available Weight: 6” I.D. = .8 lbs/ft...

10 ® U-Lok 621 With the added polyester reinforcement U-Lok 621is an all around fume and dust control duct. Available in medium gauge for added strength. Applications Acid fumes Exhaust hoods Light material handling Construction Product code: 3UL621X Material: polyester/PVC coated, black Construction: mechanical bond, corrosion resistant helix Diameters: 3” to 24” I.D. Larger sizes available Bend Radius: = 1.5 X I.D. Weight: 6” I.D. = .85 lbs/ft Length: 25 ft Compression Ratio: 6:1 Temperature Range: -20°F (-29°C) to +160°F (71°C) Colour: Yellow I.D. 3 4 5 6 8 10 12 Working Pressure/PSI 3.6 3.2...
