1300-TM Truck Mounted Material Handler specification sheet - North Shore Manufacturing - #1

Text version of the page

Truck Mounted Material Handlers Model 1300-TM BuiltriteTM, Heavy Duty, Truck Mounted Material Handlers (Back of Cab and Tail Mounts) have proven themselves in a number of applications to be the tool of choice for handling a wide variety of materials. From mining, scrap handling, utility, railroad and general construction, we can custom design a crane for all of your material handling needs. The 1300-TM is the all-around utility tool on and off the job site. Found in a wide variety of applications. It is capable of handling over 19,000 Lbs. (8,636 Kg.) at 10’ (3M). High lift capacity, excellent operator visibility and comfort make the 1300-TM an easy choice. P/N BOC 1300-TM 4-6-09 Features and Specifications: Lift Capacity (Less attachment) • 19,185 Lbs. (8,720 Kg.) @ 10’ (3M) R • 12,908 Lbs. (5,867 Kg.) @ 15’ (4.57 M) R • 9,493 Lbs. (4,315 Kg.) @ 20’ (6M) R • 7,162 Lbs. (3,255 Kg.) @ 25’ (7.6M) R Boom Data • Horizontal Reach = 23’4” (7.1M) • Vertical Reach = 34’8” (10.6M) • Main Boom Length = 14’2” (4.3M) • Jib Boom Length = 9’2” (2.8M) • High yield, fabricated steel construction. • 3” (76mm) boom pivot and 2.5” (64mm) cylinder pins with magnesium bronze bushings at all pivot points. Boom Cylinders • One 7” (178mm) bore x 41” (1,041mm) stroke x 3.5” (89mm) rod main boom cylinder. • One 7” (178mm) bore x 30” (762mm) stroke x 3” (76mm) rod jib boom cylinder. • Double acting, heavy walled, honed cylinder tube. • Wear rings on both pistons and glands. • Rods with heavy chrome plating. Swing System • 360° continuous rotation with a 39” (990mm) diameter turntable bearing, powered by two swing motors and planetary gear boxes. • Swing brake on each motor. Platform • Rotating operator’s platform with folddown, adjustable seat and 2-lever, mechanical joysticks. • Foot controlled swing. • Safety guard rail around operator. Main Frame • High tensile, heavy wall rolled steel tube. • Overall height 13’5” (4.1M) mounted on 44” (1.1M) high truck frame. Stabilizers • 14’ (4.2M), fold-away with two (2) 6” (152mm) diameter x 17” (432mm) stroke x 3” (76mm) rod cylinders. • Control valves are mounted on rotating platform for easy operator access. • Heavy duty ladder on platform side.
