® NIC COMPONENTS CORP. www.niccomp.com www.lowESR.com www.RFpassives.com www.SMTmagnetics.com 68 Surface Mount ESD Suppressor NXED Series FEATURES • IDEAL FOR USB2.0, IEEE1394 & HDMI HIGH SPEED DATA APPLICATIONS • SUPER LOW CAPACITANCE (AS LOW AS 0.05pF) • EIA SIZES 0402 AND 0603 • MEETS STANDARDS OF IEC 61000-4-2, LEVEL 4 • Pb-FREE REFLOW PROCESS COMPATIBLE Case Size Part Number Capacitance (*1) Peak Voltage (*2) Clamping Voltage (*3) Rated Voltage Leakage Current (max.) (*4) Temperature Range 0402 NXED0402S15X501TRF 0.05 ± 0.05pF 500V max. (350V typ.) 100V max. 15V max. 1ěA -55 ~ +125°C 0603 NXED0603S15Y501TRF 0.10 ± 0.1pF SPECIFICATIONS 1. Capacitance value shall be measured at 1MHz ±10%, 1V ± 0.2Vrms and 25 ± 2°C 2. Peak voltage shall be measured under the IEC61000-4-2, 8kV contact dischsrge ESD test conditions. 3. Clamping voltage shall be measured at 20ns after initiation of pulse and measured under IEC61000-4-2, 8kV contact dischsrge ESD test conditions 4. Leakage current shall be measured at 15Vdc. NXED 0603 S 15 X F RoHS Compliant Tape & Reel Rated Voltage: 15Vdc Case Size Series PART NUMBERING SYSTEM 501 TR Peak Voltage Capacitance Code: X = 0.05pF, Y = 0.1pF S = Standard Case Size L W T a b 0402 1.00 ± 0.05 0.50 ± 0.05 0.38 ± 0.05 0.20 ± 0.1 0.25±0.1 0603 1.60 ± 0.10 0.80 ± 0.10 0.50 ± 0.10 0.30 ± 0.2 0.30±0.2 L a b T W a b Structure Material Substrate AI203 Protective Coating Resin ESD Element Composite metal powder and resin Inner Electrode Thin metal fi lm Barrier Plating Nickel Termination Finish 100% Sn DIMENSIONS (mm) Termination fi nish Barrier Plating Inner electrode ESD element Substrate Protective coating NXED APPLICATIONS ESD Protection of Data Lines RoHS Compliant includes all homogeneous materials *See Part Number System for Details
