PRODUCT CATALOGUE lAST UPDATE: OCTOBER 2014

The logger sends in real time its measures to the PC. If a measure is not received by the PC, it stores it inside its internal memory and sends it to the PC on the next communication channel. They are spread in the area which has to be monitored. They send to the RF-to-USB key by radiofrequency the measures they take. They can be wireless configured and updated. 2 - THE RF-TO-USB KEY It is the bridge between the PC and the loggers. 3 - RF-MONITOR This software is installed on the PC and allows the monitoring of the loggers. The logger records in its embedded memory the measures it takes....

CREATE YOUR OWN SENSOR NETWORK… USING RF MONITOR PREMIUM The loggers communicate with a PC; the measurements are displayed only on this PC. USING RF MONITOR GOLD Several Loggers networks are created. Each system communicates to a PC that transmits the measurement to a central database. From anywhere in the world, it is possible to connect to the database to check the measurements. This consultation is possible with free software DB Monitor. >For multi-site installations.

CREATE YOUR OWN SENSOR NETWORK.. Remote consulting of the data USING AN ETHERNET OR GPRS COLLECTOR ■ The Logger equipped with a sensor takes the measure and transmits it by radio to the Collector, ■ The collector transmits the measurements through Ethernet or GPRS to a central database, ■ A real-time alert can be sent anywhere to the >The supervisor can access at any time to the measures,

Temp. Sensor Temp. Sensor Temp. Sensor

Internal Antenna Temp. Sensor Temp. Sensor Humidity Sensor* IP54 Casing ½ AA (LT) Battery * Non-condensing area Dew Point calculation and display on all our temperature and humidity loggers.

For PT100 For Newsteo Temp & Humidity probe For PT1000 For Newsteo digital Temperature probe For Thermocouple For Newsteo Double external probe of Temperature. Temp. Sensor -40°C ... +85°C± 0.3°C ATEX zone 2 gas certified Temp. Sensor Humidity Sensor

NTC probe ± 0.3 °C. End protected by a small cube End protected by a heat‐shrinkable sleeve PT100 for food contact, angle probe to insert End protected by a heat‐shrinkable sleeve Probe of stainless steel of 20mm Probe of stainless steel of 100m Probe with ribbon cable for use through a refrigerator door PT1000 with stainless steel Digital Temp. End protected by a heat‐shrinkable sleeve Digital Temp. Integrated temperature sensor Digital Temp. Integrated temperature sensor Digital Temp. Probe with ribbon cable for use through a refrigerator door PT100 with stainless steel

Digital Temp. Dual temperature probe Digital Temp. Dual temperature probe Digital Temp. Dual temperature probe, for temperature pipe monitoring Integrated temp. & humidity sensor* Integrated temp. & humidity sensor in stainless steel** Thermocouple K with probe of 250 mm Supplied with a CON05 Thermocouple K, 5 meters cable Supplied with a CON05 Thermocouple T With probe of 200 mm, cable 3 meters Supplied on a moulded connector Thermal Flux Thermal Flux Probe Thermal Flux 50x50m 0.60W/m²

LGR cable and connector References 5 meters cable – Provided with fast contactor *If you want to use your own sensor, you have to order a cable and a connector to plug it on the LG.

0 to 100% Impedance: 1 KOhm ... 65 KOhm 0 to 100% Impedance: 1 KOhm ... 65 KOhm Impulse ATEX zone 2 gas certified *Supplied on main power. External power supply needed (ref.: PFPN-ADAPT-003)

LGS cableS and connector References 5 meters cable to connect a sensor, provided with fast contactors. 5 meters cable to connect a sensor, provided with fast contactors. To directly connect the customer sensor to the LGS. To directly connect the customer sensor to the LGS. If you want to use your own sensor, you have to order a cable or a connector to plug it on the LGS.

5 meters with temperature gauge integrated and connector for FISSU-001 5 meters with temperature gauge integrated and connector for FISSU-002 Gefran PCM050 crackmeter, female connector Associated Cable Associated Cable Associated Cable 5 meters with temperature gauge integrated and connector for FISSU-003 5 meters cable, to connect any sensor, provided with fast contactors 5 meters cable, to connect any sensor, provided with fast contactors and temperature sensor

Strain gauges - Full Bridge (wheatstone bridge) cable References 5 meters cable to connect a sensor, provided with fast contactors. If you want to use your own sensor, you have to order a cable or a connector to plug it on the LGJ.

Range of measure 0 to 3 Volt 0 to 1 Volt 0 to 2 Volt 0 to 10 Volt 0 to 10 Volt 0 to 10 Volt 0 to 5 Volt Power supply for the sensor 3 Volt / 150 mA 10 Volt 12 Volt / 100 mA 12 Volt 15 Volt 15 Volt 10 Volt / 100 mA *Supplied on main power. External power supply needed (ref.: PFPN-ADAPT-003) LGW PROBES and cables References Probe of 5 meters with pyranometer integrated Probe of 5 meters for speed of air measure 5m cable, to connect any sensor, provided with fast contactors

tEMPMATE Single use USB recorder USB Connection Temperature sensor Set of 20 USB recorder Recording cycle : 5 days -30°C to 70°C ±0.5°C from -20°C to +40°C ± 1°C for other range Set of 20 USB recorder Recording cycle : 15 days -30°C to 70°C ±0.5°C from -20°C to +40°C ± 1°C for other range Lithium Battery Set of 20 USB recorder Recording cycle : 90 days -30°C to 70°C ±0.5°C from -20°C to +40°C ± 1°C for other range

Internal Antenna Operating Temp Operating Temp Internal Antenna Operating Temp

BLD Builders IP54 Casing High range Antenna with a 5m cable Temp.: -20°C ... +80°C± 0.3°C Temp.: -20°C ... +80°C± 0.3°C Deformation: -1850 ppm to +1850 ppm for a bridge excitation of 2.7 Volt

Power supply Outdoor radio relay Full Wavelength Solar panels Power supply Indoor radio relay Conventional AC Power (supplied) Outdoor radio relay Power supply Conventional AC Power (supplied)
