Design Criteria_
The ruggedized RJ45 CAT6 connection system, provides solutions for high bandwidth data transfer in harsh and demanding environments. This series offers additional headroom for high performance Fast Ethernet 100BaseT and Gigabit Ethernet 1000BaseT connectivity in audio, lighting, live stage and industrial environments and even guarantees to be prepared for future 10 Gbit applications (true CAT6). The etherCON CAT6 series offers a D-shape panel connec-tor with metal housing and secure latching system. Tool-free IDC termination makes cable assembly easy and fast. The preassembled CAT6 patch cables use a shielded S/FTP cable with cable plug carrier offering a robust metal shell and Push-Pull locking system. Integrated sealing rings make the system dust and waterproof to IP 65 rating.
Features & Benefits:
• CAT6 performance - fast data transmission and high bandwidth applications
• CAT6 specifications according TIA / EIA 568B, ISO / IEC 11801, EN 50173
• Shielded system - high noise immunity and EMI protection
• Push Pull mating - secure and proven locking system
• D-shape metal panel connector
• Ground lead jumper on panel connector with selectable grounding option
• IDC termination without tool
• Ready made patch cables with rugged cable carrier and unique chuck-type strain relief
• Dust and waterproof according IP 65
|
||||||||||||||||||||||
|
D-shape metal shell Closed shielding
|
Push Pull locking
|
IP65 in mated condition
|
|||||||||||||||||||||||
|
|
CAT6 Réceptacles
|
|
CAT6 Patch Cable
|
|
|||||||||||||||||||||
|
|
|||||||||||||||||||||||||
 |
 |
 |
|||||||||||||||||||||||
|
|
Technical Data
|
|
Receptacle Patch cable
|
Materials
Housing: Adapter:
Strain relief clamp: Contacts: Contact surface: Bushing:
|
Receptacle
|
Patch cable
|
|||||||||||||||||||
|
Electrical
Number of contacts: Rated current per contact: TIA / EIA rating: Input to output resistance: Insulation resistance: Dielectric strength: NEXT (250 MHz): Attenuation (250 MHz):
Mechanical
Retention method: Life time (mating cycles): Wire size: Stranded wire:
|
|||||||||||||||||||||||||
|
NE8FDY-C6
|
NE8FDY-C6-B
|
||||||||||||||||||||||||
|
NKE6S-*
|
Zinc diecast Zinc diecast
Polyamide PA 6 Polyamide PA 6 POM
Bronze CuSn Bronze CuSn
Gold Gold
- PU /PA
|
||||||||||||||||||||||||
|
•
|
CAT6 compliant - data rate up to 10 GBit/s IP 65 rated - with dust and waterproof resistant sealing Push Pull mating design provides secure locking system Shielded system - high noise immunity and EMI protection IDC contacts offer gas-tight termination
Ready made patch cables with rugged diecast cable carrier and unique chuck-type strain relief
|
8
1.5 A
CAT6
< 200 mQ > 500 MQ 1 kV dc 48.7 dB
0.1 dB
|
8
1.5 A CAT6
< 200 mQ > 500 MQ
1 kV dc 48.7 dB
|
||||||||||||||||||||||
|
•
|
|||||||||||||||||||||||||
|
•
|
|||||||||||||||||||||||||
|
•
|
|||||||||||||||||||||||||
|
•
|
|||||||||||||||||||||||||
|
•
|
Environmental
Operating temperature: Storage temperature: Flammability: Protection class:
|
||||||||||||||||||||||||
|
Push-Pull > T000
0.5 - 0.65 mm (AWG 24 - AWG 22)
AWG 26 / 7 - 22 / 7
|
|||||||||||||||||||||||||
|
-10°C to +60°C -40°C to +70°C UL94HB
IP 65
|
|||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||
|
NE8FDY-C6
|
NKE6S-*
|
||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||
 |
 |
|
|||||||||||||||||||||||
|
|
Ordering Information
|
|
|||||||||||||||||||||||
|
Patch Cable
|
|||||||||||||||||||||||||
|
NKE6S-* Standard lengths: 0.5, 1, 2, 3, 5, 10, 30 m
NKE6S-*-WOC Equipped on one side with metal shell, standard lengths: 0.5, 1, 2, 3, 5, 10, 30 m Custom length in meter steps on request.
|
|||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||
|
NKE6S-*-WOC
|
|||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||
 |
Receptacle
NE8FDY-C6
NE8FDY-C6-B
|
etherCON CAT6 with Nickel D-shell etherCON CAT6 with Black Chrome D-shell
|
|||||||||||||||||||||||
|
|
|||||||||||||||||||||||||
|
Accessories
Accessories see page 87
|
|||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||
 |
|
 |
|||||||||||||||||||||||
|
