| | | Crimptool | | |
| | | |
| | | + | | |
| | | |
| | | DMC crimptool AFM8 acc. M22520/2-01 | | |
| | | Crimptool HX-CONTACT | | | MPOS-* Modified DMC positioner (K155) Contact positioner helds contact in position when crimping. | | |
| | | |
| | | |
| | | |
| | | Contact and connector assembly | | |
| | | |
| | | + | | |
| | | |
| | | Crimptool HX-R-BNC | | Neutrik* HEX crimptool | | DIE-R-BNC-* Neutrik* DIE's for various HEX sizes. | | |
| | | |
| | | |
| | | | | | | | | | | | | | neutriCON - Ordering Information Assembly Tools | | | | | | | | | | Cable O.D. / Wire | Crimptool | Die/Positioner | HEX-Size/Standard | | | | | | | | SR8A | Strain relief | 3 - 3.8 mm | HX-R-BNC | DIE-R-BNC-PJ | 5.41 mm / IEC 803 | | | | SR8B | Strain relief | 6 - 7 mm | HX-R-BNC | DIE-R-BNC-PS | 7.01 mm / IEC 803 | | | | BC1 | Female crimp contact | AWG 22 -26 | HX-CONTACT | MPOS-BC1 | No. 5 / M22520/2-01 | | | | PC1 | Male crimp contact | AWG 22 -26 | HX-CONTACT | MPOS-PC1 | No. 5 / M22520/2-01 | | | | miniCON - Ordering Information Assembly Tools | | | | | | | | | | Cable O.D. / Wire | Crimptool | Die/Positioner | HEX-Size/Standard | | | | | | | | MSRC | Crimp ferrule only | 4.5 - 6 mm | HX-R-BNC | DIE-R-BNC-PDC* | 6.47 mm / IEC 803 | | | | MSRC | Crimp ferrule & reduction ferrule 1 | 3.3 - 4.4 mm | HX-R-BNC | DIE-R-BNC-PDC* | 6.47 mm / IEC 803 | | | | MSRC | Crimp ferrule & reduction ferrule 2 | 2.5 - 3.2 mm | HX-R-BNC | DIE-R-BNC-PDC* | 6.47 mm / IEC 803 | | | | MBC | Female crimp contact | 24 AWG/0.22 mm2 | HX-CONTACT | MPOS-MBC | No. 5 / M22520/2-01 | | | | MPC | Male crimp contact | 24 AWG/0.22 mm2 | HX-CONTACT | MPOS-MPC | No. 5 / M22520/2-01 | | | | | | | | | | | | | |
| | | |
| | | * DIE-R-BNC-PJ or PS also possible | | |
| | | |
| | | look for the logo | | |
| | | 122 | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | |
