DSC 204 HP Phoenix - NETZSCH-Gerätebau - #4

Highlights of the DSC 204 HP Phoenix®

• wide pressure range: vacuum ... 15 MPa (2176 psi)

• exact pressure adjustment (10 MPa ± 0.002 MPa)

• 1 bar: -150 °C to 600 °C 50 bar: -90 °C to 600 °C

150 bar: -50 °C to 450 °C

dependent on the gas type

• heating rates:

0.01 K/min to 50 K/min

• measurements in different atmospheres

- inert (N₂, He, Ar)

- reducing (H₂)

- oxidizing (0₂, air)

• exact gas flow regulation (up to 500 ml/min)

The versatile high-pressure DSC 204 HP Phoenix⁹ is part of our successful 200 series.

This also includes the heat flux Differential scanning calorimeter DSC 204 F1 Phoenix⁹ and DSC 200 F3 Maia⁹, the Thermo-micro­balances TG 209 F1 Iris⁹ and TG 209 F3 Tarsus, the Thermomechanical analyzer TMA 202, the Dynamic mechanical analyzer DMA 242 C and the Dielectric analyzer series DEA 230/231 Epsilon.

The DSC 204 HP Phoenix⁹ can also be operated simultaneously with high-temperature instruments of the 400 series in a multi-moduling mode.

Accessories:

• electronic pressure controller

• electronic gas flow controller

• adapters for various gases

• vacuum pump

• CC 200 L for controlled cooling with liquid nitrogen

• calibration kit for temperature and sensitivity

• exchangeable sensor plate
