| | | Nematron | | |
| | | |
| | | Optimate Interface Panels | | |
| | | |
| | | Broad Compatability OptiMate operator panels are compatible with most major brands of Plcs, as well as PC or microprocessor-based applications using the OptiMate Hex protocol. Easy-to-Use Software OM-WINEDIT is a graphical, user friendly software package that runs on any Windows-compatible computer. It's perfect for configuration of any OptiMate panel system, or defining all system parameters. OM-WINEDIT can be downloaded for free from www.optimate.com or purchased on CD-ROM along with OM-ACBL-1 and OM-CCBL cables to connect the PC and operator panels Hazardous Location? All OptiMate operator panels are available in models that are UL Class I, Division 2, Groups A, B, C and D certified for use in hazardous locations. | | |
| | | OptiMate 1000 Series | | |
| | | |
| | | mm 0M1224 Pushbutton Panel 24 pushbuttons pads ready for custom labels. | | |
| | | 0M1212 Button/lamp Panel 12 LED light bars and 12 pushbutton pads. | | |
| | | 0M1124 Annunciator Panel A high-intensity LED panel with 24 LED light bars. | | |
| | | |
| | | |
| | | - ■■■■ mmmm | | |
| | | |
| | | 0M1510 Operator terminal All the features of the 0 M1500, plus a configurable menu tree! | | |
| | | OMl312Setpoint Panel | | OM15O0 Operator Terminal 2x20 char. LCD with 160-msg capacity, three LED light bars, five pushbuttons, and full keypad. | | |
| | | |
| | | |
| | | |
| | | OptiMate 600 Series | | |
| | | |
| | | mmamrn | | |
| | | |
| | | 0M609 Combo Panel OM613 Operator Panel 0M620 Operator Panel 0M640 Operator Panel Six LED light bars and 4-digit numeric display, 2x20 char. LCD with 4x20 char. LCD with nine pushbutton pads. four mapped fields, 160-message capacity, 160-message capacity, two LED light bars, configurable menu tree, three LED light bars, four pushbuttons pads. five pushbuttons pads. five pushbuttons pads. | | |
| | | |
| | | |
| | | OptiMate 400 Series | | |
| | | |
| | | OM414 Setpoint/Display Panel One 8-digit numeric display and six mapped data fields. | | |
| | | 0M413 Setpoint/Display Panel One 4-digit numeiic display and six mapped data fields. | | |
| | | OM440 4-line Operator Panel 4x20 chat. LCD with 16fl-message capacity. | | |
| | | OM406 Indicator/Pushbutton Panel Six LED light bars and four pushbutton pads. | | | OM420 2-line Operator Panel 2x20 char. LCD with 160-msg capacity and four pushbuttons. | | |
| | | |
| | | |
| | | |
| | | OM9001 Communications Master The OM9001 Communications Master provides an intelligent interface between your PLC and up to 31 connected OptiMate panels (1000 Series or 600 Series). The OM9001 communicates serially to the PLC, transferring register data in both directions, and transparently manages operations amongst the OptiMate panels.The Communications Master can be configured via the OptiMate Configuration Editor to use any of several industry-standard PLC protocols. Baud rate, parity and other protocol specifics are interactively selectable to enable communications. Once configured, the OM9001 will continuously transfer data between all modules and the PLC to read and write the appropriate data registers. The OM9001 and the OptiMate panels take care of the rest. | | |
| | | |
