Specification Sheet Hand Pumps Nagman Pneumatic Hand Pump Hand held Model Combined – Vacuum & Low Pressure Hand Pump Ideal tool for checking & Calibration of Low / Very Low Pressure Digital Indicators, Manometers, Inclined Manometers, Analog (Capsule) Gauges, Draft Gauges, Differential Pressure Transmitters, Pneumatic Loops etc. Generates Low / Very Low Pressure / Vacuum with High Resolution / Sensitivity achieved thro’ Fine Adjustment Vernier & built-in Volume Chamber M o d e l PHP 2 • Compact, Light Weight, Hand Operated • Combined Vacuum & Low Pressure Pump with Pressure / Vacuum Changeover option • Generation (Range) of - Pressure : Upto 2 Bar - Vacuum : Upto 0.9 Bar • High Sensitivity / Resolution Fine Adjustment Vernier with built-in Volume Chamber to realize High Resolution / Sensitivity of around 0.05 mBar (0.5 mmWC) • Very Low Leakage rate • Flexible Nylon Hose (1 Meter) with Swivel Adaptor to connect devices under test • Test Connection Port : 1/4" (F) BSP Gauge / Indicator Connection Port : 3/8” (F) BSP • Weight (approx.) : 1.1 Kg. • Instrument Dimension (H x W x D) : 230 x 220 x 70 mm P.T.O OEM Product
