Specification Sheet Temperature Nagman Very High Temperature Dry Block Calibrator Semi-Portable with Castor Wheels Ideal for Steel, Glass, Ceramic Semi-Conductor Industries etc. for Calibration of noble Metal Thermocouples – Type R / S/ B etc. Fast, Stable & Accurate M o d e l 1500 HN • Range : 500°C to 1500°C • Accuracy : ±0.5% of Span • Fast, Stable & Accurate • Autotune PID Controller • Heating Element : Silicon Carbide • Dry Block – High Alumina Ceramic Single (Interchangeable) • Immersion Depth : 250 mm • Interchangeable Single Hole Thermowells : ID 7, 11 & 15 mm • Semi-Portable (with Castor Wheels) • RS-232 Computer Interface • “Caltemp” Calibration Software - Optional P. T.O
