Specification Sheet Hand Pumps Nagman Hydraulic Hand Pump Handheld Model for Medium Pressure Applications Ideal tool for checking & Calibration of Digital / Analog Pressure Gauges / Indicators, Pressure Transmitters / Transducers & Hydrostatic Pressure Testing etc. Generates Medium Pressure thro’ convenient Scissor action / minimum effort, Fine Adjustment Vernier & Open / Close Release Valve facilitates small Incremental Pressure adjustments M o d e l s HHP 200 / HHP 350 • Compact, Light Weight, Hand Operated • Ranges : Upto 200 / 350 Bar (3000 / 5000 PSI) • Fine Adjustment Vernier with Open / Close Release Valve for small incremental Pressure readings • Test Connection Port : 1/4" (F) BSP Gauge / Indicator Connection Port : 1/4” (F) BSP • Medium : Oil • Oil Reservoir Material : Transparent Acrylic • Reservoir Capacity : 100 cc • Instrument Dimension (H x W x D) : 270 x 150 x 110 mm • Weight (approx.) : 1.15 Kg. P.T.O OEM Product
