Catalogue excerpts

Linear and Motion Solutions near Modules 0 AXN 2008 E

 Open the catalogue to page 1

1 Directory Page 1. Product overview Basic-Line-Module AXN 3 2. Product description Basic-Line-Module AXN 4-5 Guide system Roller guide 6 Drive system Gear belt 7 3. Basic-Line-Modul AXN 45-Z 8-9 AXN 65-Z 10-11 AXN 80-Z 12-13 AXN 100-Z 14-15 4. Drive adaptor AXN-Z shaft extension / motor-adaptor 16-17 gearboxes 18 drive connecting shaft 19 5. Limit- / Position switch Switch mounting on AXN 20 specifications 21 6. Fixing- and connecting parts Fixing border / sliding block 22-23 AXN direct- / cross- / entrance connection 24-26 7. Complete systems Standard design 27 8. T-slot cover AXN 45 / 65 /...

 Open the catalogue to page 2

2 Product overview Basic Line Module AXN AXN 45 AXN 65 AXN 80 AXN 100

 Open the catalogue to page 3

3 Product overview Basic Line Module AXN AXN 45-Z AXN 65-Z AXN 80-Z AXN 100-Z 45x48 65x68,5 80x84 100x100 gear belt 100 150 180 230 325 650 1450 2500 ±0,05 ±0,05 ±0,05 ±0,05 6 10 10 10 LR24 LR35 LR42 LR52 6 6 6 6 570 995 1735 2150 570 995 1735 2150 1030 1940 2950 4500 16 35 83 125 30 70 146 330 6 17 36 75 Profil cross section w x h (mm) Drive Feed rate per rotation (mm) Max. dynamic working Load (N) Repeat accuracy (mm) Max. speed (m/s) Guide system Max. total length overall (m) * PR (N) PL (N) PT (N) MA (Nm) MB (Nm) MC (Nm) 45 65 80 100 * in one part – longer version on request Ix IY PL PT MC...

 Open the catalogue to page 4

4 Product description Basic Line Module AXN Universal motor connection Nearly all usual flange motors can be connected by metal bellow or elastomer claw couplings with the corresponding motor adapters. Gear belt tensioning device For space and cost reasons the basic line modules are equipped with gear belt tension that are located below the table plate. By positive belt retainer the gear belt get tension and laterally secure. Lifetime lubrication The bearings of the rollers and the belt pinions are lubricated for life. At any movement the steel shafts of the roller guides are coated by a thin...

 Open the catalogue to page 5

5 Product description Basic Line Module AXN Roller guide The characteristic features of the roller guide are cost-saving, nearly maintenancefree concomitant with high-performance. Resistance to soiling and smooth running is achieved by rollers of large dimensions. Integrated wiper brushes The actuator profil of the basic line modules is covered on the upper side by the circular gear belt. Wiper brushes integrated in the head covers prevent effectively larger dirt particles from penetrating into the profile. Assembly and fixation of the actuator Two longitudinal slots in the table plates (thread...

 Open the catalogue to page 6

6 Product description Drive system All sizes in the AXN line are generally provided with a roller guide system. This system consists of four roller guides, which roll along hardened steel ground shafts built into the aluminium profile. An integrated lubrication system makes sure, that the roller guide gets enough grease for a long lifetime. As a result of the eccentric bearing arrangement of the two roller guides, the guide system can be precisely adjusted and thus given the correct preload or zero backlash at the factory. This technology ensures that the roller guide system also offers outstanding...

 Open the catalogue to page 7

7 Product description Drive system Toothed belt drive Attached operating heads with integrated belt pulleys are an attribute of the AXN-Actuators. The basic-line modules AXN have been developed by maximum power rating and highest cost-benefit ratio. Operating head and deflection head are identic and will be hold in store pre-assembled. So, if stroke is known the actuators can be built in shortest time. Toothed belt clamping The ingenious design of the belt clamp enables the full width of the belt to be clamped with uniform strength so that the full load capacity of the toothed belt is guaranteed.

 Open the catalogue to page 8

8 Basic Line Module AXN 45-Z Actuator with gear belt and roller guide Stroke calculation: using distance + safty overrun * Motor connection – page 16–19

 Open the catalogue to page 9

9 Basic Line Module AXN 45-Z Max. speed Repeating accuracy Actuation Max. dynamic working load (N) Feed rate per rotation (mm) Idle-running torque Moment of inertia Max. length overall (m) 1) Geometrical moment of inertia Ix Geometrical moment of inertia Iy max. 6 m/s ± 0,05 mm/m gear belt 16 AT5 325 N 100 mm 0,2-0,3 Nm 0,383 Kgcm2 6 m 21,7 cm4 22,5 cm4 dyn. 570 570 1030 16 30 8 Technical data Roller guide 24.06 Loads and load moments* Loads (N) PR PL PT Load moments (Nm) MA MB MC stat. 1040 1040 1810 27 54 15 Mass Basic mass Mass per 100 mm stroke Slide mass Roller guide 1,8 Kg 0,3 Kg 0,5 Kg...

 Open the catalogue to page 10

10 Basic Line Module AXN 65-Z Actuator with gear belt and roller guide Stroke calculation: using distance + safty overrun * Motor connection – page 16–19

 Open the catalogue to page 11

11 Basic Line Module AXN 65-Z Max. speed Repeating accuracy Actuation Max. dynamic working load (N) Feed rate per rotation (mm) Idle-running torque Moment of inertia Max. length overall (m) 1) Geometrical moment of inertia Ix Geometrical moment of inertia Iy max. 10 m/s ± 0,05 mm/m gear belt 32 AT5 650 N 150 mm 0,8-1,0 Nm 2,994 Kgcm2 6 m 80,2 cm4 89,2 cm4 dyn. 995 995 1940 30 70 20 Technical data Roller guide 35.10 Loads and load moments* 1) Greater length upon request Loads (N) PR PL PT Load moments (Nm) MA MB MC stat. 2400 2400 3200 75 120 40 Mass Basic mass Mass per 100 mm stroke Slide mass...

 Open the catalogue to page 12

12 Basic Line Module AXN 80-Z Actuator with gear belt and roller guide Data in bracket for long carriage plate Stroke calculation: using distance + safty overrun * Motor connection – page 16–19

 Open the catalogue to page 13

13 Basic Line Module AXN 80-Z Max. speed Repeating accuracy Actuation Max. dynamic working load (N) Feed rate per rotation (mm) Idle-running torque Moment of inertia Max. length overall (m) 1) Geometrical moment of inertia Ix Geometrical moment of inertia Iy max. 10 m/s ± 0,05 mm/m gear belt 32 AT10 1450 N 180 mm 1,0-1,2 Nm 5,237 Kgcm2 6 m 198,5 cm4 207,4 cm4 dyn. stat. 1735 (2950) 3000 (5100) 1735 (2950) 3000 (5100) 2950 (5000) 5250 (8900) 83 (245) 143 (425) 146 (365) 260 (635) 36 (60) 62 (100) Technical data Roller guide 42.10 Loads and load moments* 1) Greater length upon request Loads (N)...
