Standard of high efficiency drilling and highly accurate drilling

AQUA Drill make dry drilling and high speed wet drilling possible in advance of the world, and realizes high efficiency drilling. And, AQUA Drill 3 Flutes are standard of the high accuracy in reamingres.

AQDED3

Correctional position to have superior ability_

SÉ3t£I§ Conventional process IHlLAM Eccentric amount

■8iIE-f8tt±l:WRreBo

Conventional processing, end milling was necessary before reaming. AQUA Drill 3 Flutes with end cutting teeth does not end milling, can finish.

7WI«yjUB3gfc№37J|/-h AQDED3F

FC250, T7X5mm, RUJ b8mm, TvSS 16mm, 5ËDilS765mm/min The amount of eccentric corrects it from 1mm to 0.015mm.

Selection Chart according to drilling depth

Be sure to confirm the flute length by stocked tables.


Code No.	Item	Specification	Sizes	; 3	Drilling D 5	Depth D 7	D	Cutting Fluids
AQD3F	777KUJly 37Jly-b AQUA Drills 3Flutes		03.0-016.0					7i>>b&K7-f Wet & Dry a-2
AQDED3F	7?7KU% I7№537Jl;-h AQUA Drills 3Flutes with end cutting teeth		03.0-012.0 ^^^^^					7i>>b&K7-f Wet & Dry a2
AQDS	777KUJly 77:7 AQUA Drills Stub		03.0-020.0 ^^^^^					7i>>b&K7-f Wet & Dry
AQDR	777KUJb AQUA Drills Regular		02.0-020.0 ^^^H					7i>>b&K7-f Wet & Dry
AQMD	777^-f7DKUJly AQUA Micro Drills		00.2-01.99 ^^^H					7i>>b&K7-f Wet & Dry an
AQDH	777KUJly A-K AQUA Drills Hard	Solid Drills	02.0-012.0 ^^^^					7i>>b&K7-f Wet & Dry a-3
AQDFC	777KUJU FC AQUA Drills FC		02.0-012.0 ^^^^H					7i>>b&K7-f Wet & Dry
AQMH3D	AQUA Drills with Mist-Hole(3D)		04.1-016.0 ^^^^^					7i^h&S7h Wet & MQL
AQMH5D	727hUUL/ S7h^-JK5Dffl) AQUA Drills with Mist-Hole(5D)		04.1-016.0 ^^^H					7i^h&S7h Wet & MQL
AQMH7D	727hUUL/ 57h7tv-JK7Dffl) AQUA Drills with Mist-Hole(7D)		04.1-016.0 ^^^H					7i^h&S7h Wet & MQL
AQWDS-3	777KUJ1/ 7i-ft:-3Dffl AQUA Drills WAVY(3D)		014.0-050.0 ^^^^^					7i^h Wet a-4
AQWDS-5	777KUJ1/ 7i-ft:-5Dffl AQUA Drills WAVY(5D)	Indexable Inserts	014.0-050.0 ^^^H					7i^h Wet a-4

Use in wet condition when drill size is under 1mm. ^2) For precision drilling, use drills in wet condition.

^3) Use drills in wet condition in case of work material having over 60HRC hardness. ^4) Use internal lubrication system.
