| | | WORKPLACE SYSTEMS HEIGHT-ADJUSTABLE TABLES | | WORKPLACE SYSTEMS TABLETOPS | | |
| | | |
| | | |
| | | Hydraulically height-adjustable table | | |
| | | Part N° 32.0080/0 | | |
| | | Tabletops | | |
| | | |
| | | |
| | | |
| | | There is choice of various tabletops for coping with different assembly tasks. Max. panel size is 3000 x 1200 mm. We can realize any special sizes within these dimensions. In practice, however, the dimensions stated in the tables have established themselves as standard. These standard panels are immediately available ex stock. The tabletops are attached to the base frame by mounting angle 19 and the chipboard bolts. | | |
| | | basic frame, section mat. 45x45 F, anodized E6/ EV1 footing GD, height-adjustable for floor level compensation_ mounted electrically conductive with MiniTec profile connectors_ height adjustment: sleeves of profile 45X90 S_ without tabletop, tabletops: See page 9 ff_ | | |
| | | adjustment range upper tabletop edge: H: 715 mm to 1.100 mm | | |
| | | |
| | | |
| | | max. dimensions: | | |
| | | B = 2500 mm T = 1500 mm | | |
| | | |
| | | standard height: | | H = 715 mm without tabletop | | |
| | | |
| | | preferred size: | | |
| | | B = 1500 mm T = 800 mm, | | |
| | | |
| | | |
| | | - load-carrying capacity: 3000 N at even load distribution Please specify desired dimensions B, T, H and F | | |
| | | |
| | | |
| | | Electrically height-adjustable table | | |
| | | Part N° 32.0070/0 | | |
| | | Properties Tabletops | | |
| | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | Scratches | Abrasion | Impact | Heat | Oil | Chemicals | ESD, antistatic | Light reflection | Cost factor approx. | Coating thickness | | | | Melamin | © | © | (3 | (3 | (3 | (3 | О | | С, | z'o | | | | Plastic | • | • | • | • | • | (3 | О | • | | о | | | | Linoleum | | • | • | • | • | (3 | (3 | • | L'i | | | | | Multiplex | | • | © | • | о | (3 | о | • | 00 | 1 | | | | Rubber conducting | • | (3 | © | • | • | © | • | • | L'I | o'z | | | | Melamine conducting | © | © | (3 | (3 | (3 | (3 | о | О | 9'Z | z'o | | | | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | - basic frame, section mat. 45x45 F, anodized E6/ EV1 | - adjustment range upper tabletop edge: | | | | - footing GD, height-adjustable for floor level compensation | H: 715 mm to 1.100 mm | | | | - mounted electrically conductive with MiniTec profile connectors | - max. dimensions: B = 2500 mm T = 1500 mm | | | | - height adjustment: With electric servomotor, "Up / Down" switched mounted concealed underneath tabletop, standard connection 240 VAC, synchronous table adjustment with threaded spindles mounted in column sleeves of profile 45X90 S. | - standard height: H = 715 mm without tabletop - preferred size: B = 1500 mm T = 800 mm, - load-carrying capacity: 1600 N at even load distribution | | | | - without tabletop, tabletops: See page 9 ff | Please specify desired dimensions B, T, H and F | | | | | | | | | |
| | | (^) Perfectly suitable (^) conditionally suitable (^) rather not suitable (^) unsuitable | | |
| | | |
| | | |
| | | |
| | | 8 | | MINITEC MINITEC WORKPLACE SYSTEMS - SYSTEM COMPONENTS | | MINITEC MINITEC WORKPLACE SYSTEMS - SYSTEM COMPONENTS | | 9 | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
