| | | WORKPLACE SYSTEMS BASIC TABLE RACKS | | WORKPLACE SYSTEMS HEIGHT-ADJUSTABLE TABLES | | |
| | | |
| | | |
| | | Container table | | |
| | | Part N° 32.0110/0 | | |
| | | Height-adjustable tables | | |
| | | |
| | | |
| | | |
| | | Freedom of motion is an important prerequisite for non-tiring, concentrated work. The height-adjustable tables allow fast and simple adaptation to the individual height of the employee concerned. Beyond that, the operating position between standing and seating may be varied during course of workday. Permanent postural deformities are thus prevented. | | |
| | | |
| | | basic frame, profile mat. 45x45 F, anodized E6/ EV1 footing GD, height-adjustable for floor level compensation_ mounted electrically conductive with MiniTec profile connectors | | max. dimensions: | | |
| | | B = 2500 mm T = 1500 mm | | |
| | | |
| | | seated work position: H = 678 mm without tabletop | | |
| | | |
| | | standing work position: H = 878 mm without tabletop | | |
| | | |
| | | preferred size: | | |
| | | B = 1500 mm T = 800 mm, | | |
| | | |
| | | |
| | | |
| | | without tabletop | | load-carrying capacity: 2000 N at even load distribution | | |
| | | |
| | | |
| | | Tabletops: See page 9 ff | | OPTIONAL: Three-piece screen, chipboard 8 mm, light gray | | |
| | | |
| | | |
| | | Please specify desired dimensions B, T and H | | |
| | | |
| | | Desk table | | Mechanically height-adjustable table | | |
| | | Part N° 32.0120/0 | | | Part N° 32.0060/0 | | |
| | | |
| | | |
| | | |
| | | |
| | | basic frame, profile mat. 45x45 F, anodized E6/ EV1 footing GD, height-adjustable for floor level compensation_ mounted electrically conductive with MiniTec profile connectors | | max. dimensions: | | |
| | | B = 2500 mm T = 1500 mm | | |
| | | adjustment range upper tabletop edge: H= 715 mm up to 1.100 mm | | |
| | | basic frame, section mat. 45x45 F, anodized E6/ EV1 ■ footing GD, height-adjustable for floor level compensation_ ■ mounted electrically conductive with MiniTec profile connectors_ ■ height adjustment: By means of retractable crank handle, mounted underneath tabletop, synchronous table adjustment with threaded spindles in profile 45x90 S column sleeves_ ■ without tabletop_ ■ tabletops: See page 9 ff_ | | |
| | | |
| | | seated work position: H = 678 mm without tabletop | | |
| | | |
| | | |
| | | max. dimensions: | | |
| | | B = 2500 mm T = 1500 mm | | |
| | | standing work position: H = 878 mm without tabletop | | |
| | | |
| | | |
| | | standard height: | | H = 715 mm without tabletop | | |
| | | preferred size: | | |
| | | B = 1500 mm T = 800 mm, | | |
| | | |
| | | |
| | | |
| | | |
| | | preferred size: | | |
| | | B = 1500mm | | T = 800 mm, | | |
| | | without tabletop | | load-carrying capacity: 2000 N at even load distribution | | |
| | | |
| | | |
| | | |
| | | |
| | | |
| | | - load-carrying capacity: 2000 N at even load distribution Please specify desired dimensions B, T, H and F_ | | |
| | | Tabletops: See page 9 ff | | OPTIONAL: Three-piece screen, chipboard 8 mm, light gray | | |
| | | |
| | | |
| | | |
| | | |
| | | Please specify desired dimensions B, T and H | | |
| | | |
