INSTALLATION PROCEDURE G2002 & G2003 H-MATIC

MAIN COMPONENTS

1. Hydraulic head 2. Carriage 3. Guide rail of the hydraulic head 4. Matrix 5. Frame 6. Gauge pin 7. Comb 8. Belt clamp 9. Belt grip 10. Power point (Hexagon 13 mm - ½") 11. Advance lever 12. Release lever 13. Belt clamp lever 14. Head clamp security bolts 15.Head clamping assembly 16.Presser 17.Avoid the zone of moving parts when jointing

MLT

Minet Lacing Technology WWW.mlt-eu.com
Rev. : 5 15/02/2006 1/3 Assembly instruction H-Matic for G2002 & G2003 .doc
