| | | Thermistor Thermal-Ribbons™ | | |
| | | |
| | | Overview | | |
| | | |
| | | Model TS665 and TS667 offer extremely sensitive NTC thermistors for applications with small temperature changes. Model TS667 also features waterproof construction, making it suitable for continuous immersion. Specifications | | |
| | | |
| | | | | | | | | | | | | | | | Dimensions WxLxTmax | Element options | Insulation | Temperature range | Leadwires | Time constant | Features | Model | | | | 0.20 x 0.47 x 0.079"" (5.0 x 12.0x2.0 mm) | TF,TK | Polyimide with elastomer cover coat | -50 to 125°C (-58 to 257°F) | AWG 26, PTFE insulated | 0.8 sec. | Small, low-cost | TS665 | | | | 0.20x0.60x0.118"" (5.0 x 15.2x3.0 mm) | Silicone rubber with elastomer cover and foil backing | AWG 24, Silicone insulated | 1.3 sec. | Waterproof, suitable for continuous immersion | TS667 | | | | | | | | | | | | | | | |
| | | |
| | | Notes: Tmax is measured over the lead bulge. *Time constant is in water at 1 m/sec | | |
| | | Specification and order options | | |
| | | |
| | | | | | | | | | TS665 | Model number from table | | | | TF | Sensing element from table | | | | Y | Number of leads: Y = 2 leads | | | | 40 | Lead length in inches: 40" stocked, 60" maximum | | | | A | Adhesive backing: A = No adhesive B = Pressure-sensitive adhesive (PSA) | | | | N | Compliancy: C = RoHS compliant N = RoHS non-compliant | | | | TS665TFY40AN = Sample part number | | | | | | | | | |
| | | |
| | | Sensing elements | | |
| | | |
| | | | | | | | | | Sensing element specifications** | Code | | | | NTC thermistor 50k Q ±1%at25°C | TF | | | | NTC thermistor 10k Q ±1%at25°C | TK | | | | | | | | | |
| | | |
| | | **See table above for element options on each model. | | |
| | | |
| | | Specify and order products at: www.minco.com/sensors_config | | |
| | | |
| | | Note: PSA reduces temperature range to -20 to 177°C (-4 to 350°F) and adds 0.005" (0.1 mm) to thickness. | | |
| | | |
| | | |
| | | Thermocouple Thermal-Ribbon™ | | |
| | | |
| | | Overview TC40 is a patch-style thermocouple that adheres to all types of Specifications | | |
| | | surfaces for quick and easy mounting. Specification and order options | | |
| | | |
| | | |
| | | | | | | | | | TC40 | Model number | | | | J | Junction type: E, J, K,orT | | | | T | Covering over leadwires: T = PTFE only S = Stainless steel braid | | | | 36 | Lead length in inches: 36" and 144" are stocked for type J, K, T | | | | A | Adhesive backing: A = No adhesive B = Pressure-sensitive adhesive (PSA) | | | | TC40JT36A = Sample part number | | | | | | | | | |
| | | | | | | | | | Dimensions WxLxTmax | 0.75x0.75x0.065" (19.1 x 19.1 x 1.7 mm) —m | | | | Junction type | E, J, K,orT | | | | Insulation | Polyimide | | | | Temperature range | -200 to 200°C (-328 to 392°F) | | | | Leadwires | AWG 24, solid PTFE insulated | | | | Time constant | 0.6 sec. | | | | Features | Surface mounting | | | | Model | TC40 | | | | | | | | | |
| | | |
| | | |
| | | Notes: Tmax is measured over the lead bulge. *Time constant is in water at 1 m/sec. | | |
| | | Note: PSA reduces temperature range to -20 to 177°C (-4 to 350°F) and adds 0.005" (0.1 mm) to thickness. | | |
| | | |
| | | |
