| | | Strip Sensing Thermal-Ribbons™ | | |
| | | |
| | | Overview | | |
| | | |
| | | These models average temperatures along their length to eliminate point measurement errors. Wrap them around cylinders or adhere them to flat surfaces. Specifications | | |
| | | |
| | | | | | | | | | | | | | | | Dimensions WxLxTmax | Element options | Insulation | Temperature range | Leadwires | Time constant* | Features | Model | | | | 0.375 x 4.00 x 0.075" (9.5 x 101.6 x 1.9 mm) | PB22 | Silicone rubber with polyimide backing | -62 to 220°C -80 to 428°F | AWG 26, PTFE insulated | 0.6 sec. | Platinum PD accuracy | S34 | | | | PD12 PE22 | S386 | | | | 0.375 x 4.00 x 0.065" (9.5 x 101.6 x 1.7 mm) | FA | Polyimide | -200 to 200°C -328 to 392°F | 0.2 sec. | Wire-wound nickel-iron for high resistance, thin element | S35 | | | | FA | Mylar | -100 to 150°C -148 to 302°F | 0.3 sec. | Wire-wound nickel-iron, low cost | S2 | | | | 0.50 x 1.25x0.050" (12.7 x 31.8 x 1.3 mm) ^ _ -19 | PA, PE, CA, NA | Polyimide | -73 to 200°C -100 to 392°F | 0.17 sec. | Easy motor installations | S3238 | | | | | | | | | | | | | | | |
| | | |
| | | Notes: Tmax is measured over the lead bulge. *Time constant is in water at 1 m/sec. | | |
| | | |
| | | | | | | | | | Sensing element specifications** | Code | | | | Platinum (0.00391 TCR) 100 Q ±0.5% at 0°C | PA | | | | Platinum (0.00391 TCR) 100 Q ±0.22% at 0°C | PB22 | | | | Platinum (0.00385 TCR) 100 Q ±0.12% at 0°C (EN60751, Class B) | PD12 | | | | Platinum (0.00385 TCR) 100 Q ±0.5% at 0°C | PE | | | | Platinum (0.00385 TCR) 100 Q ±0.22% at 0°C | PE22 | | | | Nickel-iron (0.00518 TCR) 604 Q ±0.26% at 0°C | FA | | | | Copper 427 10 Q ±0.20% at 25°C | CA | | | | Nickel 672 120 Q ±0.3%at0°C | NA | | | | | | | | | |
| | | Model S3238 Model S3238 is specially designed to sense stator temperatures in motors and generators. An alternative to the "stick" sensors, the S3238 mounts on the end turns of stator windings and provides an easy way to add overtemperature protection when the stator is not being rewound. S3238 specification and order options | | |
| | | |
| | | | | | | | | | S3238 | Model number S3238 | | | | PA | Sensing element from table | | | | Y | Number of leads: Y = 2 leads (not available on CA) Z = 3 leads X = 4 leads | | | | T | Lead insulation: T = PTFE K = polyimide TS = SS braid over PTFE | | | | 36 | Lead length in inches 36" stocked | | | | U | Lead configuration: T = Twisted U = Untwisted | | | | A | Adhesive backing: A = No adhesive B = Pressure-sensitive adhesive (PSA) | | | | S3238PAYT36UA = Sample part number | | | | | | | | | |
| | | |
| | | **See table above for element options on each model. Specification and order options | | |
| | | |
| | | | | | | | | | S34 | Model number from table (except S3238) | | | | PB22 | Sensing element from table | | | | Y | Number of leads: Y = 2 leads Z = 3 leads (required on CA) X = 4 leads (PDonly) | | | | 36 | Lead length in inches 36"" stocked (42"" on S2) | | | | A | Adhesive backing: A = No adhesive B = Pressure-sensitive adhesive (PSA) | | | | S34PB22Y36A = Sample part number | | | | | | | | | |
| | | |
| | | Notes: PSA reduces temperature range to -20 to 177°C (-4 to 350°F) and adds 0.005" (0.1 mm) to thickness. | | |
| | | |
| | | Specifications subject to change | | |
| | | |
| | | |
| | | Page 10-5 | | |
