| | | Discoil™ Thermal-Ribbons | | |
| | | |
| | | Overview Install these compact sensors anywhere for accurate point sensing. Discoil™ RTD elements are wound on a single plane for faster time response. | | |
| | | |
| | | Specifications | | |
| | | |
| | | | | | | | | | | | | | | | Dimensions WxLxTmax | Element options | Insulation | Temperature range | Leadwires | Time constant* | Features | Model | | | | 0.79 x 1.87x0.055" (20x47.5x 1.4 mm) solder pad version shown | PD, PE | Polyimide (clear polyester available) | -73 to 200°C -100 to 392°F | (Optional) AWG 24, PTFE insulated | 0.10sec. | Only 0.010" thick over element, fast time response, platinum PD accuracy available | S17422 | | | | 1.00 x 1.25 x 0.090" (25.4x31.8x2.3 mm) | PB11, PB22 | Silicone rubber with polyimide backing | -62 to 220°C -80 to 428°F | AWG 24, silicone rubber insulated | 0.2 sec. | High temperature rating, platinum PD accuracy available | S32 | | | | PD12, PE22 | S385 | | | | 1.00 x 1.25 x 0.065" (25.4x31.8x1.7 mm) | FA | Polyimide | -200 to 200°C -328 to 392°F | AWG 26, PTFE insulated | 0.15 sec. | High resistance nickel-iron element | S39 | | | | | | | | | | | | | | | |
| | | |
| | | Notes: Tmax is measured over the lead bulge. *Time constant is in water at 1 m/sec Sensing elements | | |
| | | Specification and order options | | |
| | | |
| | | | | | | | | | S32 | Model number from table | | | | PB22 | Sensing element from table | | | | Z | Number of leads: Y = 2 leads Z = 3 leads X = 4 leads W = Solder pads (S17422 only) | | | | 36 | Lead length in inches (Specify 0 for solder pads, option on S17422 only) | | | | A | Adhesive backing: A = No adhesive B = Pressure-sensitive adhesive (PSA) | | | | S32PB22Z36A = Sample part number | | | | | | | | | |
| | | | | | | | | | Sensing element specifications** | Code | | | | Platinum (0.00391 TCR) 100 Q ±0.11% at 0°C | PB11 | | | | Platinum (0.00391 TCR) 100 Q ±0.22% at 0°C | PB22 | | | | Platinum (0.00385 TCR) 100 Q ±0.12% at 0°C (EN60751, Class B) | PD, PD12 | | | | Platinum (0.00385 TCR) 100 Q ±0.36% at 0°C | PE | | | | Platinum (0.00385 TCR) 100 Q ±0.22% at 0°C | PE22 | | | | Nickel-iron (0.00518 TCR) 604 Q ±0.26% at 0°C | FA | | | | | | | | | |
| | | |
| | | **See table above for element options on each model. | | |
| | | |
| | | |
| | | Notes: PSA reduces temperature range to -20 to 177°C (-4 to 350°F) and adds 0.005" (0.1 mm) to thickness. Specify and order products at: www.minco.com/sensors_config | | |
| | | |
| | | Specifications subject to change | | |
| | | |
