| | | Specifications, continued | | Specification and order options | | |
| | | |
| | | | | | | | | | S17624 | Model number from table | | | | PD | Sensing element from table | | | | Z | Number of leads: Y= 2 leads Z = 3 leads (N/A on S25, S38) X = 4 leads (N/A on S25, S38 or S665/S667) | | | | T | Leadwire insulation code from table at left | | | | 24 | Lead length in inches: S665/S667: 60" max. | | | | A | Adhesive backing: A = No adhesive B = Pressure-sensitive adhesive (PSA) | | | | N | Compliancy: C = RoHS compliant N = RoHS non-compliant | | | | S17624PDZT24AN = Sample part number | | | | | | | | | |
| | | | | | | | | | Leadwire insulation codes | | | | S25, S38, 5651, S665, S667 | Leave blank | | | | S17624, S100721, S100723, S100724, S100725, S100820 | T = PTFE insulated wires K = Polyimide insulated wires | | | | | | | | | |
| | | |
| | | Sensing elements | | |
| | | |
| | | | | | | | | | | Sensing element specifications** | Code | | | | Platinum (0.00385 TCR) (EN60751, Class B) | 100 Q ±0.12% at 0°C | PD | | | | Platinum (0.00385 TCR) | 100 Q ±0.36% at 0°C | PE | | | | Platinum (0.00385 TCR) | 1000 Q ±0.12% at 0°C | PF | | | | Platinum (0.00375 TCR) | 1000 Q ±0.12% at 0°C | PW | | | | Platinum (0.00385 TCR) | 10,000 Q ±0.12% at 0°C | PS | | | | Nickel-iron (0.00518TCR) | 604 Q ±0.26% at 0°C | FA | | | | Nickel (0.00618 TCR) 100 Q ±0.22% at 0°C (DIN43760 NI100, Class B) | NB | | | | Nickel (0.00672 TCR) | 120 Q ±0.50% at 0°C | NA | | | | Nickel (0.00618 TCR) 1,000 Q ±0.22% at 0°C (DIN43760 NI1000, Class B) | NJ | | | | | | | | | | |
| | | |
| | | Notes: PSA reduces temperature range to -20 to 177°C (-4 to 350°F) and adds 0.005" (0.1 mm) to thickness. | | |
| | | |
| | | Specify and order products at: www.minco.com/sensors_config | | |
| | | |
| | | **See table on previous page for element options on each model. | | |
| | | |
| | | |
| | | Waterproof model | | |
| | | Custom Thermal-Ribbon designs_ Minco can custom-wind Thermal-Ribbon elements in virtually any shape and size. We can profile sensing elements to provide increased sensitivity in selected zones, and provide packaging to perfectly fit your applications. | | |
| | | |
| | | Model S667 is waterproof and suitable for continuous immersion. Use it to monitor the temperature of water in a tank or container, or on equipment that must withstand wash-down or immersion. Check with Minco for suitability in other liquids. | | |
| | | |
| | | Contact Access: Minco Sales and Support today to discuss your application. | | |
| | | |
| | | |
| | | Specifications subject to change | | |
| | | |
| | | Sensors & Instruments Solutions Guide I www.minco.com Page 10-3 | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
