| | | Thermal-Tab™ and Thermal-Ribbon™ Sensors | | |
| | | |
| | | Install these compact sensors anywhere for accurate point sensing and fast response. All Thermal-Tab modules use a thin-film RTD element. All Thermal-Ribbon models conform to EN60751 Class B tolerance when ordered with a PD platinum element. Thermal-Tab Specifications | | Rugged lamination construction Polyimide, silicone rubber or Mylar™ insulation | | |
| | | |
| | | |
| | | Element options | | Insulation | | Leadwires | | Model | | |
| | | Dimensions WxLxTmax | | | Temperature range | | | Time constant* | | Features | | |
| | | | | |
| | | |
| | | |
| | | |
| | | 0.20 x 0.50 x 0.08" (5 x12 x2 mm) | | |
| | | Polyimide with elastomer cover coat | | |
| | | -50 to 155°C -58to311°F | | AWG 26, PTFE insulated | | Stocked for immediate shipment | | |
| | | PD, PF, PW | | |
| | | S665 | | |
| | | 0.8 sec. | | |
| | | |
| | | | |
| | | |
| | | |
| | | |
| | | 0.20 x 0.60 x 0.08" (5x15x2mm) | | |
| | | PD, PF, PW, PS, NB, NA, NJ | | AWG 26, PTFE or polyimide insulated | | |
| | | -50 to 200°C -58 to 392°F | | | Platinum models in stock | | |
| | | Polyimide | | |
| | | S17624 | | |
| | | 1.0 sec. | | |
| | | |
| | | | |
| | | |
| | | |
| | | |
| | | |
| | | 0.20 x 0.60 x 0.08" (5x15x2mm) | | |
| | | AWG 26, PTFE or polyimide insulated | | |
| | | PD, PF, PW, PS | | -50 to 260°C -58 to 500°F | | | Highest temperature capability | | |
| | | Polyimide film | | |
| | | S100820 | | |
| | | 0.4 sec. | | |
| | | |
| | | | |
| | | |
| | | |
| | | |
| | | |
| | | 0.20x0.60x0.12" (5 x15 x3 mm) | | |
| | | Silicone rubber with elastomer cover and foil backing | | |
| | | AWG 24, Silicone insulated | | Waterproof; suitable for continuous immersion | | |
| | | -50 to 155°C -58to311°F | | |
| | | PD, PF, PW | | |
| | | S667 | | |
| | | 1.3 sec. | | |
| | | |
| | | | |
| | | |
| | | |
| | | |
| | | |
| | | 0.20 x 0.60 x 0.045" (5 x 15 x 1.15 mm) | | |
| | | AWG 26, PTFE or polyimide insulated | | |
| | | -50 to 200°C -58 to 392°F | | |
| | | Polyimide film | | |
| | | PD, PF, PW | | | Thinnest profile | | |
| | | S100725 | | |
| | | 0.6 sec. | | |
| | | |
| | | | |
| | | |
| | | |
| | | |
| | | |
| | | |
| | | 0.30x0.60x0.10" (7 x 15 x 2.5 mm) | | |
| | | Heavier leadwire for applications requiring ruggedized design | | |
| | | PD, PF, PW, PS, NB, NA, NJ | | AWG 22, PTFE or polyimide insulated | | |
| | | -50 to 200°C -58 to 392°F | | |
| | | Polyimide film | | |
| | | S100724 | | |
| | | 1.2 sec. | | |
| | | |
| | | | |
| | | |
| | | |
| | | |
| | | |
| | | Larger surface area for easier handling and maximum adhesive bond | | |
| | | 0.40 x 0.80 x 0.08" (10x20x2mm) | | |
| | | PD, PF, PW, PS, NB, NA, NJ | | AWG 26, PTFE or polyimide insulated | | |
| | | -50 to 200°C -58 to 392°F | | |
| | | Polyimide film | | |
| | | S100723 | | |
| | | 0.9 sec. | | |
| | | |
| | | | |
| | | |
| | | |
| | | |
| | | |
| | | High temperature rating, available with wide range of element options | | |
| | | 0.40 x 0.80 x 0.08" (10x20x2mm) | | |
| | | PD, PF, PW, PS, NB, NA, NJ | | AWG 26, PTFE or polyimide insulated | | |
| | | -50 to 220°C -58 to 428°F | | |
| | | Silicone rubber | | |
| | | S100721 | | |
| | | 1.5 sec. | | |
| | | |
| | | | | |
| | | |
| | | |
| | | |
| | | Thermal-Ribbon Specifications | | |
| | | |
| | | | | | | | | | | | | | | | 0.20 x 1.50x0.030" (5.1 X38.1 x 0.8 mm) | FA | Polyimide | -200 to 200°C -328 to 392°F | AWG 34, PTFE insulated | 0.15 sec. | Wire-wound nickel-iron for high resistance in small package | S38 | | | | 0.30x0.30x0.025" (7.6 x 7.6 x 0.7 mm) | PD, PE | Polyimide with foil backing | -200 to 200°C -328 to 392°F | AWG 28, PTFE insulated | 0.15 sec. | Wire-wound element | S651 | | | | 0.75 x 0.75 x 0.04" (19x 19 x 1.0 mm | FA | Mylar | -200 to 150°C -328 to 302°F | AWG 30, PTFE insulated | 0.3 sec. | Wire-wound nickel-iron flat element for high resistance | S25 | | | | | | | | | | | | | | | |
| | | |
| | | Notes: Tmax is measured over the lead bulge. *Time constant is in water at 1 m/sec | | |
| | | |
| | | Specifications subject to change | | |
| | | |
