Elements & Probes

LEAD LENGTHCASE LENGTH0.250" (6.4 mm) DIAMETER0.188" (4.8 mm) DIAMETER1.0" (25.4 mm)SENSING TIP

Overview

These models feature fast-responding RTD or thermistor ele-ments in aluminum cases (except stainless steel on S482PW) with PTFE insulated leadwires. They can be assembled into probes or used separately as all-purpose sensors.Probes consist of elements assembled into stainless steel exten-sion tubes. They are not suitable for direct fluid immersion but may be used with thermowells. See Section 4 for thermowell options.See Section 5for optional 4 to 20 mA temperature transmitters. LEAD LENG T H2.00" * (50.8 mm)0. 1 88" (4.8 mm) DIAME T ERMODEL S482PW IS 2.4" ( 6 0.3 mm) LONG

Specifications

Temperature range: -45.5 to 135°C (-50 to 275°F).

Specification and order options:ElementsProbes

Leadwires: AWG 22, PTFE insulated. Standard lengths are 4",12" and 18". S458PD Model number from table Moisture resistance: Meets MIL-STD-202, Method 104, TestCondition B. Z Number of leads: Y=2 leadsZ=3 leads (platinum only) Insulation resistance: 1000 megohms min. at 500 VDC, leadsto case. 4 Lead length in inches S458PDZ4 = Sample part number

Model numbers

Element TCR Elements Probes S411PB Model number from table Ω / Ω / °C Case length: RTDs Specify in 0.1" increments (Ex: 60 = 6.0 inches) Minimum length is 3" Platinum100 Ω ±0.1% at 0°C 0.00391 S402PB 411PB 6
HVAC SENSORS Platinum100 Ω ±0.1% at 0°C(Meets EN60751, Class B) 0.00385 S458PD S4 6 0PD Number of leads: Platinum1000 Ω ±0.1% at 0°C 0.00385 S459PF S4 6 1PF Z Y=2 leadsZ=3 leads (platinum only) Platinum1000 Ω ±0.1% at 0°C 0.00375 S482PW S485PW Nickel-iron1000 Ω ±0.12% at 70°F 0.00527 S400FB S409FB 4 Lead length in inches Nickel-iron2000 Ω ±0.12% at 70°F 0.00527 S401FC S410FC S411PB 6 0Z4 = Sample part number HW3000 Ω at -30.2°C 0.00262 S100057PX S100837PX Thermistors
R 25 ¼
R 125

Specify and order products at:

Thermistor2,252 Ω ±1% at 25°C 29.2 TS438TA TS440TA

www.minco.com/sensors_config

Thermistor10,000 Ω ±1% at 25°C 23.5 TS439TB TS441TB
Specifications subject to change

|

Page 9-19
