| | | Overview • Monitor water or chemical solution temperature in cooling tower sumps and storage tanks • True continuous averaging sensor eliminates errors due to temperature stratification • Stainless steel case is rugged and impervious to most chemicals • Bend or manipulate the probe to accommodate a variety of sump and tank designs • Specify the overall probe length and the length of the temperature-sensitive zone to fully immerse the sensitive zone in liquid • NEMA 4 weatherproof connection head | | |
| | | Leads: AWG 22, Teflon insulated, 8 inches in length. | | |
| | | |
| | | |
| | | Specifications Temperature range: -50°F to 275°F (-45°C to 135°C). RTD Probe: 100 Q platinum equivalent, 0.00385 TCR element in a 304 stainless steel bendable case. Also available in 1000 Q resistance. Dimensions in inches (millimeters): - L ±6.0" (152.4) - | | |
| | | |
| | | - 0 0.250 (6.35) | | |
| | | Specification and order options | | |
| | | |
| | | |
| | | | | | | | | | S100479 | Model Number | | | | PE | 100 Q platinum curve RTD | | | | 12 | Insertion length L in feet: Standard lengths = 6, 12, 18, 24 | | | | Z | Number of leads: Y = 2 leads Z = 3 leads | | | | 6 | Temperature-sensitive zone length S in feet: Standard lengths = 3, 6, 9, 12 | | | | S100479PE12Z6 = Sample part number | | | | | | | | | | |
| | | "S" REF -«f- 4.0 - Temperature (101.6) sensitive zone | | |
| | | |
| | | 4.3 (109.2) | | |
| | | V4-14NFT | | |
| | | |
| | | -V4-14NPT | | |
| | | |
| | | |
| | | Specify and order products at: www.minco.com/sensors_config | | |
| | | |
| | | Specifications subject to change | | |
| | | |
