5.8" ( 1 47 mm) T HERMOWELL LENG T H U0.375" ½ - 1 4 NP T (9.5 mm) DIAME T ER OP T IONAL T IONHEAD T HERMOWELLALUMINUMPROBE T RANSMI TT ERCONNEC T IP Overview
Immersion sensors include stainless steel
thermowells for insertion directly into fluid streams. The sensing probe may be
removed without breaking the fluid seal. Brass thermowells are also available.See page 5-2 for optional 4 to 20 mA
industrial temperature transmitters.
Specification and order options:Fluid immersion temperature sensors
Replacement stainless steel thermowells
S479PD Model number from table
Specifications
Y Number of leads: Y=2 leads
Z=3 leads Temperature range: -45.5 to 2 6 0°C (-50 to 500°F). Leadwires: AWG 22, PTFE insulated, 4" (100 mm) long. 6 Thermowell length U: Specify in 0.1" increments
(Ex: 60 = 6.0 inches)
Standard thermowell lengths are 3" and 6", contact factory for other lengths Thermowell pressure rating: 1880 psi (130 bar). Moisture resistance: Meets MIL-STD-202, Method 104, Test Condition B. S479PDY 6 0 = Sample part number
Model numbers
Element TCR Model number TW488 Model number Ω / Ω /°C U
HVAC SENSORS Platinum100 Ω ±0.1% at 0°C 0.00391 S478PB Platinum100 Ω ±0.1% at 0°C(Meets EN60751, Class B) 0.00385 S479PD 6 Thermowell length U: Specify in 0.1" increments
(Ex: 60 = 6.0 inches)
Standard thermowell lengths are
3" and 6", contact factory for other lengths Platinum1000 Ω ±0.1% at 0°C 0.00385 S480PF Platinum1000 Ω ±0.1% at 0°C 0.00375 S490PW * Nickel-iron1000 Ω ±0.12% at 70°F 0.00527 S47 6 FB * TW488U 6 0 = Sample part number Nickel-iron2000 Ω ±0.12% at 70°F 0.00527 S477FC * HW 3000 Ω at -30.2°C 0.00262 S1000 6 1PX *
Specify and order products at:
* Maximum temperature is 130°C (266°F). www.minco.com/sensors_config
Note: These sensors are intended for use in slow-moving fluid streams. For applications where fluid velocity exceeds 3 ft/s, you may need to use a thermowell assembly as an alternative. Please consult Access: Minco Sales and Support for technical guidance. Specifications subject to change |
Page 9-17
