Refrigeration & Freezer Temperature System

Overview

•Ideal for refrigerated rooms, freezers, cold storage facilitiesand laboratories — anywhere an accurate, rugged, and weatherproof temperature sensor is needed.•100 Ω platinum RTD probe is constructed of 31 6 9°C).•4 to 20 mA transmitter is epoxy potted to protect circuitryfrom condensation and ice. Operates in ambient temperatures down to -13°F (-25°C).•Transmitter is match calibrated to RTD for 0.75% systemaccuracy. Free NIST certificate.•Enclosure is gasketed and moisture resistant. •RTD probe is available in lengths ranging from 2 inches to 48inches, and the probe can be center-mounted for through- the-wall installation, or end-mounted for flush-to-the-wall mounting. 6 stainlesssteel to be resistant to most chemicals, including ammonia. Operates to -452°F (-2

Specification and order options

AS100279 Assembly number PD 100 Ω platinum RTD 6 7 Probe length: Specify in 0.1" increments(Ex: 67 = 6.7 inches)

Specifications

M Temperature range for 4-20 mA output: Probe: -2 6 9 to 2 6 0°C (-452 to 500°F).Transmitter: -25 to 85°C (-13 to 185°F). M=-50 to 50°C(-58 to 122°F)AD=-40 to 48.9°C(-40 to 120°F) DN=-30 to 50°C(-22 to 122°F) S=-18 to 37.8°C(0 to 100°F) BY=-10 to 40°C(14 to 104°F)Other ranges are available on page 5-16. Temperature range: RTD probe: 100 Ω platinum, 0.00385 TCR. Transmitter: 4-20 mA output, 8.5 to 35 VDC loop powered. AS100279PD 6 7M= Sample part number 2.75(70) 0. 1 0(2.5)

Specify and order products at:

T H

www.minco.com/sensors_config

½ - 1 4 NP T[ 3 ] 4.50( 11 4)0.25( 6 .4) DIA.2.30(58)PROBELENG
7 8 HEX
Specifications subject to change Page 9-1 6

|
