Thermal Vial™ Temperature Sensing System

Specifications

Probe case: Stainless steel. Element: Platinum. Resistance (excluding leadwire resistance): PM platinum:100.00 Ω ±.0 6 % at 0°C (32°F)(Class A).PD platinum:100.00 Ω ±.12% at 0°C (32°F)(Class B).PF platinum:1000.00 Ω ±.12% at 0°C (32°F). TCR: .00385 Ω / Ω /°C nominal from 0°C to 100°C. Operating temperature range: Probe and vial: -200 to 120°C (-328 to 248°F). Transmitter: -25 to 85°C (-13 to 185°F). Insulation resistance: 1000 megohms minimum at 500 VDC,leads to probe case. Leads: AWG #22, stranded, TFE insulated, with TFE jacket overall. Thermal vial: Polyethylene bottle with cap. Thermowell: Delrin material.

Overview

Transmitter: 4-20 mA output; 8.5 to 35 VDC loop powered. •Ideal for ultralow freezers, laboratories, blood banks, walk-in freezers and refrigerators, even industrial incubators— anywhere accurate sensing of the contents instead of the air is a vital concern.•Sealed Polyethylene Thermal Vial™ eliminates spillage andcontamination. Simply fill with fluid such as ethylene glycol, alcohol, water, or a cryopreservative to accurately emulatethe material being stored or processed.•Large (50 mm x 50 mm) footprint of the single well vial provides stability on a shelf or rack. Holds 175 ml ( Connection box: Polycarbonate enclosure, NEMA 4X. 6 oz) of fluid.Other vial configurations are available. See next page.•Platinum RTD probe is constructed of 31

Specification and order options

6 Stainless Steel andoperates to -200°C (-328°F). •Metal shielded cable is rugged and washdown proof. •4 to 20 mA transmitter is match calibrated to the RTD forimproved system accuracy. •System accuracy is a variable •NIST certificate and calibration data supplied at no additional cost.•Additional accessories available. •Customizable for validation requirements. •Connection box and indicator are polycarbonate and NEMA4X sealed to be washdown proof. AS103282 Model number PD Sensing element, .00385 TCR: PM=100 Ω Platinum ±.06%, Class APD=100 Ω Platinum ±.12%, Class BPF=1000 Ω Platinum ±.06% 72 Cable length in inches D Vial configuration: S=Single thermowell, standard vialD=Dual thermowell T=Triple thermowell M=Single thermowell, miniature vial L=Single thermowell, large vial C Connection box type: C=Indicating °CF=Indicating °F B=Non-indicating 75 System accuracy: 75=.75% of span50=.50% of span 20=.20% of span or .1°C, whichever is greater EZ Temptran temperature range code: EZ= -100/0°C(-148/32°F)M= -50/50°C(-58/122°F) C= 0/100°C( 32/212°F) More ranges on page 5-16.

Specify and order products at:

www.minco.com/sensors_config

AS103282PD72D75CEZ = Sample part number
Specifications subject to change Page 9-14

|
